Honda Jazz GG facelift (2011-2014) low tire pressure indicator wiring diagram
This page shows the only wiring diagram for the component.low tire pressure indicator, which is found in the car Honda Jazz GG facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
low tire pressure indicator wiring diagram (1 of 1)
+B BACK UP
+B TPMS
AREA NETWORK CONTROLLER
BLK WIRE
BLU WIRE
CAN L
COMPUTER DATA LINES SYSTEM
DRIVE CIRCUIT
FAST CONTROLLER AREA
FUSE 1
FUSE 2
FUSE 22
GAUGE CONTROL MODULE
HOT AT ALL TIMES
HOT IN ON OR START
K LINE
LOW TIRE PRESSURE INDICATOR
LT BLU WIRE
METER
MICU
NETWORK TRANSCEIVER
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
TPMS CONTROL UNIT
TPMS INDICATOR
UNDER-DASH FUSE/RELAY BOX
WARNING
WHT WIRE
Go to component -> Tire pressure monitoring circuit, except electric vehicle -> LOW TIRE PRESSURE INDICATOR
