Honda Jazz GG facelift (2011-2014) left front impact sensor Wiring diagrams
This page contains all the electrical diagrams for the component. left front impact sensor, in which he is found in the car Honda Jazz GG facelift (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front impact sensor (1 of 2)
BATTERY CONDITION MONITOR MODULE
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
COMPUTER DATA LINES SYSTEM
DRIVER'S AIR BAG INFLATOR (IN STEERING WHEEL)
FRONT PASSENGER'S AIR BAG INFLATOR
FUSE 6
FUSE 8
GRN WIRE
HOT IN ON OR START
LEFT FRONT IMPACT SENSOR
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RIGHT FRONT IMPACT SENSOR
SRS UNIT
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, electric vehicle (1 of 4) -> LEFT FRONT IMPACT SENSOR
Wiring diagram left front impact sensor (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
CAN HI
CAN LO
COMPUTER DATA LINES
DRIVER'S AIR BAG FIRST INFLATOR
DRIVER'S AIR BAG SECOND INFLATOR
FRONT PASSENGER'S AIR BAG FIRST INFLATOR
FRONT PASSENGER'S AIR BAG SECOND INFLATOR
FUSE 22
FUSE 6
FUSE 8
GRN WIRE
HOT IN ON OR START
K LINE
LEFT FRONT IMPACT SENSOR
LFS-
LT BLU WIRE
LT GRN WIRE
METER
MICU
OPDS
ORG/ WIRE
PPL
PTT
RED WIRE
RFS-
RIGHT FRONT IMPACT SENSOR
SRS
SRS GND (1)
SRS GND 2
SRS UNIT
STEERING WHEEL)
SYSTEM
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, except electric vehicle (1 of 3) -> LEFT FRONT IMPACT SENSOR
