Honda Jazz GG facelift (2011-2014) ignition switch connector Wiring diagram
This page shows the only wiring diagram for the component.ignition switch connector, which is found in the car Honda Jazz GG facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ignition switch connector (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DLC (DATA LINK CONNECTOR)
ECM/PCM
IGNITION SWITCH
IGNITION SWITCH CONNECTOR
LOCK
LT BLU WIRE
LT GRN WIRE
MICU
NCA WIRE
ORG/ WIRE
PADDLE SHIFTERS
PNK WIRE
POWER DISTRIBUTION SYSTEM
SCS
START RELAY
TRANSMISSION RANGE SWITCH
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH FUSE/RELAY BOX CONNECTOR Q
W/O PADDLE SHIFTERS
WHT WIRE
YEL WIRE
Go to component -> Remote starting circuit (2 of 2) -> IGNITION SWITCH CONNECTOR
