Honda Jazz GG facelift (2011-2014) front passenger's side air bag inflator Wiring diagrams
This page contains all the electrical diagrams for the component. front passenger's side air bag inflator, in which he is found in the car Honda Jazz GG facelift (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram front passenger's side air bag inflator (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER SEAT POSITION SENSOR
DRIVER'S SIDE AIR BAG INFLATOR
FRONT PASSENGER'S SEAT BELT TENSIONER
FRONT PASSENGER'S SIDE AIR BAG INFLATOR
GRN WIRE
GRY WIRE
LEFT "C" PILLAR)
LEFT SIDE CURTAIN AIR BAG INFLATOR
LEFT SIDE IMPACT SENSOR (FIRST)
LEFT SIDE IMPACT SENSOR (SECOND)
LT BLU WIRE
LT GRN WIRE
LT PPL PNK WIRE
PNK WIRE
PPL
RED WIRE
RIGHT SIDE CURTAIN AIR BAG INFLATOR
RIGHT SIDE IMPACT SENSOR (FIRST)
RIGHT SIDE IMPACT SENSOR (SECOND)
SRS UNIT
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, electric vehicle (4 of 4) -> FRONT PASSENGER'S SIDE AIR BAG INFLATOR
Wiring diagram front passenger's side air bag inflator (2 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT BELT TENSIONER
DRIVER'S SEAT POSITION SENSOR
DRIVER'S SIDE AIR BAG INFLATOR
FLBC
FRBC
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
FRONT PASSENGER'S SEAT BELT TENSIONER
FRONT PASSENGER'S SIDE AIR BAG INFLATOR
GRN WIRE
GRY WIRE
LEFT SIDE CURTAIN AIR BAG INFLATOR
LRP-
LSA -
LT BLU WIRE
LT GRN WIRE
LT LT
ODS
ORG/ WIRE
PNK WIRE
PPL
RED WIRE
RIGHT SIDE CURTAIN AIR BAG INFLATOR
RRP
RSA-
SRS UNIT
SS+
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit, except electric vehicle (2 of 3) -> FRONT PASSENGER'S SIDE AIR BAG INFLATOR
