Honda Jazz GG facelift (2011-2014) fan control relay Wiring diagrams
This page contains all the electrical diagrams for the component. fan control relay, in which he is found in the car Honda Jazz GG facelift (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
fan control relay wiring diagram (1 of 3)
A/C CONDENSER FAN MOTOR
A/C CONDENSER FAN RELAY
A/C MAIN RELAY
BATTERY CONDITION MONITOR MODULE
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
ECT SENSOR 2
ELECTRIC WATER PUMP
FAN CONTROL RELAY
FUSE 30
FUSE 39
FUSE 43
FUSE 47
FUSE 52
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RADIATOR FAN MOTOR
RADIATOR FAN RELAY
RED WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (4 of 4) -> FAN CONTROL RELAY
fan control relay wiring diagram (2 of 3)
A/C CONDENSER FAN MOTOR
A/C CONDENSER FAN RELAY
AUXILIARY UNDER-HOOD FUSE BOX
BATTERY CONDITION MONITOR MODULE
BATTERY TERMINAL FUSE BOX
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
COOLING EWP RELAY
ECT SENSOR 2
ELECTRIC WATER PUMP
FAN CONTROL RELAY
FUSE 1
FUSE 30
FUSE 39
FUSE 47
FUSE 52
FUSE 8
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
ON BATTERY)
PNK WIRE
POWER CONTROL UNIT
PPL
RADIATOR FAN MOTOR
RADIATOR FAN RELAY
RED WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit, electric vehicle -> FAN CONTROL RELAY
fan control relay wiring diagram (3 of 3)
3 MODE SWITCH
A/C CONDENSER FAN MOTOR
BLK WIRE
BLOWER MOTOR RELAY
BRAKE FLUID LEVEL SWITCH
BRAKE PEDAL STROKE SENSOR SHIELD
CABLE REEL
CHARGE INDICATOR
CHARGE LID ACTUATOR
CHARGE LID OPENER SWITCH
CRUISE CONTROL COMBINATION SWITCH
DATA LINK CONNECTOR (DLC)
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
ELECTRIC SERVO BRAKE CONTROL UNIT
ELECTRIC WATER PUMP
ELECTRICAL COOLANT HEATER
EPS MOTOR/EPS MOTOR ANGLE SENSOR
FAN CONTROL RELAY
GAUGE CONTROL MODULE
HORN SWITCH
ILLUMINATION LAMP SWITCH
IMMOBILIZER KEYLESS CONTROL UNIT
KM/H, MPH CHANGE SWITCH
LEFT FRONT PARKING LIGHT/SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT BULB
LT GRN WIRE
M/C RELAY
MANAGEMENT ECU
POWER KEY SWITCH
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
TELEMATICS CONTROL UNIT
UNDER- DASH FUSE/ RELAY BOX
UNDER-DASH FUSE/RELAY BOX
VSA OFF SWITCH
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit, electric vehicle (2 of 3) -> FAN CONTROL RELAY
