Honda Jazz GG facelift (2011-2014) auxiliary under hood relay box Wiring diagrams
This page contains all the electrical diagrams for the component. auxiliary under hood relay box, in which he is found in the car Honda Jazz GG facelift (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
auxiliary under hood relay box wiring diagram (1 of 3)
A/C CONDENSER FAN MOTOR
A/C CONDENSER FAN RELAY
AIR CONDITIONING SYSTEM
AREA NETWORK
AUXILIARY UNDER HOOD RELAY BOX
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT
COMPUTER DATA LINES SYSTEM
COOLANT HIGH TEMPERATURE IND
COOLANT LOW TEMPERATURE IND
DIMMING
DRIVE CIRCUIT
ECM/PCM (LEFT SIDE OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR 1
ENGINE COOLANT TEMPERATURE (ECT) SENSOR 2
FAST CONTROLLER
FUSE 10
FUSE 22
FUSE 30
FUSE 47
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
INDICATOR
LT BLU WIRE
LT GRN WIRE
METER
MICU
NETWORK CONTROLLER
RADIATOR FAN MOTOR
RADIATOR FAN RELAY
RED WIRE
RED/BLK WIRE
RELAY CONTROL (FANC)
SENSOR GROUND
SENSOR INPUT
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX
WARNING
WHT WIRE
YEL WIRE
Go to component -> Cooling fan circuit, except electric vehicle -> AUXILIARY UNDER HOOD RELAY BOX
auxiliary under hood relay box wiring diagram (2 of 3)
A/C COMPRESSOR CLUTCH RELAY
A/C CONDENSER FAN RELAY
ACS HAC
AUXILIARY UNDER HOOD RELAY BOX
BLK WIRE
BLOWER MOTOR RELAY
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ECM (LEFT SIDE OF ENGINE COMPT)
ENGINE COOLANT TEMPERATURE (ECT) SENSOR 1
ENGINE COOLANT TEMPERATURE (ECT) SENSOR 2
EVAPORATOR TEMPERATURE SENSOR
FUSE 10
FUSE 22
FUSE 30
FUSE 43
FUSE 47
FUSE 57
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
METER
MICU
ORG/ WIRE
PNK WIRE
RADIATOR FAN RELAY
RED WIRE
RELAY CTRL (ACC)
RELAY CTRL (FANC)
SENSOR GROUND
SENSOR INPUT
SENSOR INPUT (TAC)
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 2) -> AUXILIARY UNDER HOOD RELAY BOX
auxiliary under hood relay box wiring diagram (3 of 3)
A/C
A/C CONDENSER FAN RELAY
A/C SWITCH
A/T
A/T GEAR POSITION INDICATOR PANEL LIGHT
A/T GEAR POSITION INDICATOR PANEL LIGHT/ PARK PIN SWITCH/ SHIFT LOCK SOLENOID
ACCESSORY
AUDIO REMOTE SWITCH
AUDIO UNIT
AUDIO- NAVIGATION UNIT
AUXILIARY UNDER HOOD RELAY BOX
BLK WIRE
BLOWER MOTOR RELAY
CABLE REEL
CONSOLE BOX LIGHT
CRUISE CONTROL
CRUISE CONTROL COMBINATION SWITCH
ETCS CONTROL RELAY
FOG LIGHT SWITCH
FROM FUSE 29 (DIAGRAM 3 OF 5)
FROM FUSE 46 (DIAGRAM 2 OF 5)
FROM TAILLIGHT RELAY (DIAGRAM 3 OF 5)
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUSE 29
FUSE 47
FUSE 52
FUSE 53
FUSE 57
GRY WIRE
HANDS- FREE LINK
HAZARD WARNING SWITCH
HEATER-A/C CONTROL PANEL
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT FRONT PARKING/ SIDE MARKER LIGHT
LEFT LICENSE
MICU
MULTI-FUSE 60
PLATE LIGHT
POWER MIRROR SWITCH
REAR WINDOW DEFOGGER SWITCH
REAR WINDOW/POWER MIRROR DEFOGGERS SWITCH
RED WIRE
RED/BLK WIRE
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT FRONT PARKING/ SIDE MARKER LIGHT
RIGHT LICENSE
STEERING WHEEL)
TAILLIGHT RELAY
TO FUSE 52 (DIAGRAM 3 OF 5)
TO FUSE 59 (DIAGRAM 1 OF 5)
TO IGNITION SWITCH (DIAGRAM 4 OF 5)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 5)
VOICE CONTROL SWITCH
VSA OFF SWITCH
W/ NAVIGATION
W/ POWER MIRROR DEFOGGERS
W/O NAVIGATION
WHT WIRE
Go to component -> Power distribution circuit, except electric vehicle (3 of 5) -> AUXILIARY UNDER HOOD RELAY BOX
