Honda Jazz GG facelift (2011-2014) a/t gear position indicator panel light Wiring diagrams
This page contains all the electrical diagrams for the component. a/t gear position indicator panel light, in which he is found in the car Honda Jazz GG facelift (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram a/t gear position indicator panel light (1 of 2)
+B BACK UP
0 OFF 1 PARK 2 HEAD
A/T
A/T GEAR POSITION INDICATOR PANEL LIGHT
A/T GEAR POSITION INDICATOR PANEL LIGHT/ PARK PIN SWITCH/SHIFT LOCK SOLENOID
AMBIENT LIGHT IN LINE FUSE
AMBIENT LIGHT SWITCH
B-CAN
BACK-UP
BLK WIRE
BLU WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
COURTESY LAMPS CIRCUIT
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUSE 1
FUSE 22
FUSE 29
GRY WIRE
H/L OFF COMBI SW GND
H/L ON SW
HAZARD WARNING SWITCH
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
METER
MICU
P-GND P-GND
PNK WIRE
POWER MIRROR SWITCH
POWER MIRROR SWITCH CONNECTOR
RED WIRE
RED/BLK WIRE
S GND
SMALL LT SW
SWITCH ILLUMI- NATION
TAILLIGHT RELAY
UNDER-DASH FUSE/RELAY BOX
VSA OFF SWITCH
W/ HONDA ACCESSORY W/O HONDA ACCESSORY
WHT WIRE
Go to component -> Instrument illumination circuit, except electric vehicle (1 of 2) -> A/T GEAR POSITION INDICATOR PANEL LIGHT
Wiring diagram a/t gear position indicator panel light (2 of 2)
A/C
A/C CONDENSER FAN RELAY
A/C SWITCH
A/T
A/T GEAR POSITION INDICATOR PANEL LIGHT
A/T GEAR POSITION INDICATOR PANEL LIGHT/ PARK PIN SWITCH/ SHIFT LOCK SOLENOID
ACCESSORY
AUDIO REMOTE SWITCH
AUDIO UNIT
AUDIO- NAVIGATION UNIT
AUXILIARY UNDER HOOD RELAY BOX
BLK WIRE
BLOWER MOTOR RELAY
CABLE REEL
CONSOLE BOX LIGHT
CRUISE CONTROL
CRUISE CONTROL COMBINATION SWITCH
ETCS CONTROL RELAY
FOG LIGHT SWITCH
FROM FUSE 29 (DIAGRAM 3 OF 5)
FROM FUSE 46 (DIAGRAM 2 OF 5)
FROM TAILLIGHT RELAY (DIAGRAM 3 OF 5)
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUSE 29
FUSE 47
FUSE 52
FUSE 53
FUSE 57
GRY WIRE
HANDS- FREE LINK
HAZARD WARNING SWITCH
HEATER-A/C CONTROL PANEL
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT FRONT PARKING/ SIDE MARKER LIGHT
LEFT LICENSE
MICU
MULTI-FUSE 60
PLATE LIGHT
POWER MIRROR SWITCH
REAR WINDOW DEFOGGER SWITCH
REAR WINDOW/POWER MIRROR DEFOGGERS SWITCH
RED WIRE
RED/BLK WIRE
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT FRONT PARKING/ SIDE MARKER LIGHT
RIGHT LICENSE
STEERING WHEEL)
TAILLIGHT RELAY
TO FUSE 52 (DIAGRAM 3 OF 5)
TO FUSE 59 (DIAGRAM 1 OF 5)
TO IGNITION SWITCH (DIAGRAM 4 OF 5)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 3 OF 5)
VOICE CONTROL SWITCH
VSA OFF SWITCH
W/ NAVIGATION
W/ POWER MIRROR DEFOGGERS
W/O NAVIGATION
WHT WIRE
Go to component -> Power distribution circuit, except electric vehicle (3 of 5) -> A/T GEAR POSITION INDICATOR PANEL LIGHT
