Honda Jazz GG facelift (2011-2014) active bodyworks system Wiring diagram
This page shows the only wiring diagram for the component.active bodyworks system, which is found in the car Honda Jazz GG facelift (2011-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram active bodyworks system (1 of 1)
ACTIVE BODYWORKS SYSTEM
ACTIVE BODYWORKS, ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DOOR LOCKS SYSTEM
DOOR LOCKS, ENGINE CONTROLS SYSTEMS
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
FUSE 1
FUSE 10
FUSE 14
FUSE 15
FUSE 21
FUSE 22
FUSE 23
FUSE 24
FUSE 27
FUSE 28
FUSE 29
FUSE 5
FUSE 56
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR ACC
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
MICU
MICU SERVICE CHECK CONNECTOR
OPTIONAL CONNECTOR
PNK WIRE
POWER WINDOWS SYSTEM
PPL
SEATS, MIRRORS, AIR CONDITIONING SYSTEMS
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
YEL WIRE
Go to component -> Body control modules circuit, electric vehicle (1 of 2) -> ACTIVE BODYWORKS SYSTEM
