Honda Inspire VI facelift (2021-2023) left lower tail/stop, turn signal lamp Wiring diagram
This page shows the only wiring diagram for the component.left lower tail/stop, turn signal lamp, which is found in the car Honda Inspire VI facelift (2021-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left lower tail/stop, turn signal lamp (1 of 1)
AUDIO AMPLIFIER
AUXILIARY AUDIO INPUT
BACKUP ALARM
BLK WIRE
BLK/WHT WIRE
BLUNT CUT)
BRAKE FLUID LEVEL SWITCH
CARGO LAMP PROVISION
DRIVER INFORMATION CENTER DISPLAY
DRIVER SEAT ADJUSTER SWITCH
DRIVER SEAT LUMBAR SUPPORT SWITCH
ELECTRONIC BRAKE CONTROL MODULE
HUMAN MACHINE INTERFACE CONTROL MODULE
HVAC CONTROLS
INFO DISPLAY MODULE
LEFT BACKUP LAMP
LEFT CARGO LAMP
LEFT LICENSE PLATE LAMP
LEFT LOWER TAIL/STOP, TURN SIGNAL LAMP
LEFT TAIL LAMP ASSEMBLY
LEFT UPPER TAIL/STOP, TURN SIGNAL LAMP
NCA WIRE
PASSENGER INSTRUMENT PANEL AIR BAG
PASSENGER SEAT ADJUSTER SWITCH
PASSENGER SEAT LUMBAR SUPPORT SWITCH
RADIO
REAR AUXILIARY AUDIO INPUT
REAR VIEW CAMERA
RIGHT CARGO LAMP
RIGHT LICENSE PLATE LAMP
SEAT HEATING CONTROL MODULE
TRAILER CONNECTOR
TRAILER PROVISION
W/ NAVIGATION
W/ TRAILER CONNECTOR
W/O TRAILER CONNECTOR
WHT WIRE
Go to component -> Ground distribution circuit (4 of 5) -> LEFT LOWER TAIL/STOP, TURN SIGNAL LAMP
