Car Wiring Diagrams for Headlamps circuit for Honda Insight ZE4 (2018-2024)

0 = LOW 1 = HIGH 2 = PASSING 0) OFF 1) PARK 2) AUTO 3) HEAD BLK WIRE BLU WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) BRN WIRE COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM DIMMER/ FLASH-TO- PASS SWITCH FUSE 10 FUSE 22 FUSE 7 GRY WIRE HEADLIGHT SWITCH HOT AT ALL TIMES HOT W/ LT BLU WIRE LT GRN WIRE PNK WIRE PPL PPL/BRN WIRE RED WIRE RELAY CONTROL MODULE UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT WIRE WINDSHIELD WIPER CONTROL UNIT/MOTOR YEL WIRE

AUTO HIGH BEAM IND (GREEN) AUTOMATIC DIMMING INSIDE MIRROR/ HOMELINK UNIT AUTOMATIC LIGHTING CONTROL UNIT/SENSOR AUTOMATIC LIGHTING/RAIN SENSOR B-CAN B-CAN H B-CAN L BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX C GAUGE CONTROL MODULE LED CONTROL UNIT LEFT HEADLIGHT LIGHTS ON IND LT GRN WIRE PNK WIRE PPL PPL/BRN WIRE RED WIRE RIGHT HEADLIGHT TAN WIRE TRANSCEIVER/ YEL WIRE
