Honda Insight ZE4 (2018-2024) thermal joint 3 Wiring diagrams

A/C PRESSURE SENSOR AUTOMATIC LIGHTING CONTROL UNIT/SENSOR BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S JUNCTION BOX C ECT SENSOR 1 ECT SENSOR 2 ENGINE CONTROLS SYSTEM FUSE 1 1 FUSE 1-2 FUSE 7 FUSE/RELAY HOLDER A GRN WIRE GRY WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN ON OR START LT BLU WIRE LT GRN WIRE PCM PNK WIRE PPL PTC HEATER A RELAY PTC HEATER B RELAY RADIATOR FAN MOTOR RED WIRE TAN WIRE THERMAL JOINT 3 UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

A/C PRESSURE SENSOR ABOVE A/C COMPRESSOR) BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ECT SENSOR 1 ECT SENSOR 2 ELECTRIC ENGINE COOLANT PUMP ENGINE CONTROLS SYSTEM ENGINE EWP RELAY FUSE 1-7 FUSE 2-5 FUSE 6 FUSE 9 FUSE/RELAY HOLDER C GRN WIRE GRY WIRE HOT AT ALL TIMES LT GRN WIRE PCM PNK WIRE PPL RADIATOR FAN MOTOR RADIATOR FAN RELAY RED WIRE RELAY ENERGIZED TAN WIRE THERMAL JOINT 3 UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX YEL WIRE

APPLY SWITCH AUTOMATIC BRAKE HOLD SWITCH BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SWITCH DRIVER'S JUNCTION BOX C ELECTRIC PARKING BRAKE SWITCH ELECTRIC PARKING BRAKE/AUTOMATIC BRAKE HOLD SWITCH (UNDER CENTER CONSOLE) ELECTRIC SERVO BRAKE CONTROL UNIT/ PEDAL FEEL SIMULATOR ENGINE CONTROLS SYSTEM FRONT PASSENGER'S DOOR SWITCH FUSE 10 FUSE 30 GRN WIRE GRY WIRE HOT AT ALL TIMES LEFT REAR DOOR SWITCH LT GRN WIRE PCM PNK WIRE PPL PPL/GRN WIRE PPL/TAN WIRE RED WIRE RELEASE SWITCH RIGHT REAR DOOR SWITCH ROCKER ARM OIL PRESSURE SENSOR TAN WIRE THERMAL JOINT 3 UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX VSA MODULATOR CONTROL UNIT WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BODY CONTROL MODULE BRAKE LIGHT RELAY BRN WIRE COMPUTER DATA LINES SYSTEM ENGINE CONTROLS SYSTEM FUSE 16 FUSE 2-3 FUSE 25 FUSE 28 FUSE 6 FUSE/RELAY HOLDER B FUSE/RELAY HOLDER C GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE PARK PAWL ACTUATOR PARK PAWL ACTUATOR DRIVER UNIT PARK PAWL ACTUATOR RELAY PCM (RIGHT SIDE OF ENGINE COMPT) PNK WIRE PPL PPL/GRN WIRE PPL/PNK WIRE RED WIRE RELAY CIRCUIT BOARD SHIFT SOLENOID VALVE A TAN WIRE THERMAL JOINT 3 TRANSMISSION FLUID PRESSURE SENSOR UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

0) OFF 1) PARK 2) AUTO 3) HEAD ANTI-LOCK BRAKES SYSTEM AUTOMATIC LIGHTING CONTROL UNIT/SENSOR AUTOMATIC LIGHTING/RAIN SENSOR B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BLU WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) BRAKE FLUID LEVEL SWITCH BRAKE SYSTEM INDICATOR BRN WIRE BUZZER COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SWITCH DRIVER'S SEAT BELT BUCKLE SWITCH ENGINE CONTROLS SYSTEM FRONT PASSENGER'S DOOR SWITCH FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH FUSE 7 FUSE 8 GAUGE CONTROL MODULE (BEHIND INSTRUMENT CLUSTER) GRN WIRE GRY WIRE HEADLIGHT SWITCH LEFT REAR DOOR SWITCH LIGHTS ON INDICATOR LOW TIRE PRESSURE/ TPMS INDICATOR LT GRN WIRE PCM PNK WIRE PPL PPL/GRN WIRE PPL/TAN WIRE RED WIRE RELAY CONTROL MODULE RELAY ENERGIZED RIGHT REAR DOOR SWITCH ROCKER ARM OIL PRESSURE SENSOR SEAT BELT REMINDER INDICATOR SRS UNIT (UNDER CENTER OF DASH) THERMAL JOINT 3 TRUNK LID LATCH SWITCH/TRUNK LID RELEASE ACTUATOR TRUNK LIGHT UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

BLK WIRE BLU WIRE BRN WIRE CMP SENSOR A CMP SENSOR B FUSE 21 GRN WIRE IAT SENSOR 2 ICM IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 LT BLU WIRE LT GRN WIRE PARK PAWL ACTUATOR DRIVER UNIT PCU PNK WIRE PPL PPL/BLU WIRE PPL/GRN WIRE PPL/LT BLU WIRE PPL/PNK WIRE PPL/RED WIRE PPL/TAN WIRE PPL/YEL WIRE RED WIRE RELAY ENERGIZED ROCKER ARM OIL PRESSURE SENSOR SPARK PLUG TAN WIRE THERMAL JOINT 3 TRANSMISSION FLUID PRESSURE SENSOR UNDER- DASH FUSE/ RELAY BOX UNDERHOOD FUSE/RELAY BOX YEL WIRE
