Honda Insight ZE4 (2018-2024) left side curtain air bag inflator Wiring diagram
This page shows the only wiring diagram for the component.left side curtain air bag inflator, which is found in the car Honda Insight ZE4 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left side curtain air bag inflator (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BELT OUTER LAP TENSIONER
DRIVER'S SEAT POSITION SENSOR
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FRONT PASSENGER'S SEAT BELT OUTER LAP TENSIONER
FRONT PASSENGER'S SEAT BELT TENSIONER
FRONT PASSENGER'S WEIGHT SENSOR (FRONT INNER SIDE)
FRONT PASSENGER'S WEIGHT SENSOR (REAR INNER SIDE)
GAUGE CONTROL MODULE
GRN WIRE
LEFT SIDE CURTAIN AIR BAG INFLATOR
LT BLU WIRE
PNK WIRE
PPL
RED WIRE
SEAT BELT REMINDER IND
SELECTABLE ENERGY ABSORPTION DEVICE
SRS IND
TAN WIRE
W/ POWER SEAT
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> LEFT SIDE CURTAIN AIR BAG INFLATOR
