Honda Insight ZE4 (2018-2024) ighldb relay Wiring diagram
This page shows the only wiring diagram for the component.ighldb relay, which is found in the car Honda Insight ZE4 (2018-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ighldb relay (1 of 1)
BATTERY CONDITION MONITOR MODULE
BATTERY FAN RELAY
BATTERY MODULE
BATTERY MODULE 2
BATTERY PACK (UNDER REAR SEAT)
BLU WIRE
BRN WIRE
GRN WIRE
GRY WIRE
IDENTIFICATION RESISTOR
IGHLDB RELAY
LT BLU WIRE
LT GRN WIRE
NCA WIRE
PNK WIRE
PPL
RED WIRE
TAN WIRE
TEMPERATURE SENSOR 1
TEMPERATURE SENSOR 2
TEMPERATURE SENSOR 3
WHT WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 1.5l hybrid, hybrid system circuit (6 of 6) -> IGHLDB RELAY
