Honda Insight ZE4 (2018-2024) f-can h Wiring diagrams
This page contains all the electrical diagrams for the component. f-can h, in which he is found in the car Honda Insight ZE4 (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram f-can h (1 of 12)
ACOUSTIC VEHICLE ALERTING CONTROL UNIT
ACOUSTIC VEHICLE ALERTING SPEAKER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX C
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 5
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
PPL
RED WIRE
RELAY ENERGIZED
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
YEL WIRE
Go to component -> Active bodyworks circuit -> F-CAN H
Wiring diagram f-can h (2 of 12)
ABS INDICATOR
APPLY SWITCH
AUTOMATIC BRAKE HOLD INDICATOR
AUTOMATIC BRAKE HOLD SWITCH
AUTOMATIC BRAKE HOLD SYSTEM INDICATOR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE LIGHT RELAY
BRAKE SYSTEM INDICATOR (AMBER)
BRAKE SYSTEM INDICATOR (RED) WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC PARKING BRAKE/AUTOMATIC BRAKE HOLD SWITCH (UNDER CENTER CONSOLE)
ELECTRIC SERVO BRAKE CONTROL UNIT/ PEDAL FEEL SIMULATOR
F-CAN
F-CAN H
F-CAN L
FUSE 21
FUSE 30
FUSE 34
FUSE 5
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PCM
PNK WIRE
PPL
RED WIRE
RELAY CIRCUIT BOARD UNDER-HOOD FUSE/RELAY BOX
RELAY ENERGIZED
RELEASE SWITCH
SAFETY SUPPORT/VSA OFF SWITCH
TAN WIRE
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX
VSA INDICATOR
VSA OFF INDICATOR
VSA OFF SWITCH
W/ SAFETY SUPPORT SWITCH/VSA OFF SWITCH
W/O SAFETY SUPPORT SWITCH/VSA OFF SWITCH
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> F-CAN H
Wiring diagram f-can h (3 of 12)
ACC COMBINATION SWITCH
BLK WIRE
BRN WIRE
CANCEL SWITCH
CIRCUIT
COMPUTER DATA LINES SYSTEM
CRUISE SWITCH
DISTANCE SWITCH
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 1
FUSE 21
FUSE 34
FUSE 5
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT W/ ACC RELAY ENERGIZED
LKAS SWITCH
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RES/+ SWITCH
SET SWITCH
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (3 of 3) -> F-CAN H
Wiring diagram f-can h (4 of 12)
APPLY SWITCH
AUTOMATIC BRAKE HOLD IND
AUTOMATIC BRAKE HOLD SWITCH
AUTOMATIC BRAKE HOLD SYSTEM IND
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRAKE SYSTEM IND (AMBER)
BRAKE SYSTEM IND (RED) WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC PARKING BRAKE/AUTOMATIC BRAKE HOLD SWITCH (UNDER CENTER CONSOLE)
ELECTRIC SERVO BRAKE CONTROL UNIT/ PEDAL FEEL SIMULATOR
F-CAN
F-CAN H
F-CAN L
FUSE 30
FUSE 34
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RELEASE SWITCH
TAN WIRE
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Electric parking brake circuit (2 of 2) -> F-CAN H
Wiring diagram f-can h (5 of 12)
AUTOMATIC BRAKE HOLD IND
AUTOMATIC BRAKE HOLD SYSTEM IND
BLK WIRE
BLU WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRAKE HOLD SWITCH
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRAKE PEDAL STROKE SENSOR
BRAKE SYSTEM IND (AMBER)
BRAKE SYSTEM IND (RED) WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH (LEFT "B" PILLAR)
ELECTRIC PARKING BRAKE/ AUTOMATIC BRAKE HOLD SWITCH
ELECTRIC SERVO BRAKE CONTROL UNIT/ PEDAL FEEL SIMULATOR
EXTERNAL DRIVE 4 PIN CONNECTOR
F-CAN
F-CAN H
F-CAN L
FUSE 1-6
FUSE 16
FUSE 20
FUSE 21
FUSE 5
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HALL SENSOR
HOT AT ALL TIMES
HOT W/
LT BLU WIRE
MOTOR
PCM
PNK WIRE
PPL
PPL/BLU WIRE
PPL/BRN WIRE
RED WIRE
RELAY CIRCUIT BOARD
TAN WIRE
TANDEM MOTOR CYLINDER (RIGHT REAR OF ENGINE COMPT)
TRANSCEIVER/
UNDER- DASH FUSE/ RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Electric servo brake system circuit -> F-CAN H
Wiring diagram f-can h (6 of 12)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
EPS CONTROL UNIT
EPS IND
EPS MOTOR
EPS MOTOR ANGLE SENSOR
F-CAN
F-CAN H
F-CAN L
FUSE 2-6
FUSE 34
FUSE 7
GAUGE CONTROL MODULE
GRY WIRE
HOT AT ALL TIMES
NCA WIRE
PPL
RED WIRE
RELAY ENERGIZED
TAN WIRE
TORQUE SENSOR
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
Go to component -> Electronic power steering circuit -> F-CAN H
Wiring diagram f-can h (7 of 12)
ABS INDICATOR
ANTI-LOCK BRAKES SYSTEM
AUTO HIGH-BEAM INDICATOR (GREEN)
AUTOMATIC BRAKE HOLD INDICATOR
AUTOMATIC BRAKE HOLD SYSTEM INDICATOR
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE SYSTEM INDICATOR (AMBER)
BRAKE SYSTEM INDICATOR (RED) WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DASHLIGHTS BRIGHTNESS CONTROL/TRIP SWITCH
ENCODER
ENGINE CONTROLS SYSTEM
EPS INDICATOR
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FOG LIGHT INDICATOR
FUEL GAUGE SENDING UNIT
FUEL TANK UNIT
FUSE 10
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HIGH BEAM INDICATOR
HOT AT ALL TIMES
ILLUMINATION CONTROL
LEFT TURN SIGNAL INDICATOR
LIGHTS ON INDICATOR
LIN TRANSCEIVER
LOW TIRE PRESSURE/ TPMS INDICATOR
LT GRN WIRE
MALFUNCTION INDICATOR LAMP (MIL)
NCA WIRE
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RIGHT TURN SIGNAL INDICATOR
SEAT BELT REMINDER INDICATOR
SECURITY INDICATOR
SOUND SYSTEMS
SPORT MODE/ECON/EV SWITCH
SRS INDICATOR
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
VSA INDICATOR
VSA OFF INDICATOR
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> F-CAN H
Wiring diagram f-can h (8 of 12)
ACC COMBINATION SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
COMPUTER DATA LINES SYSTEM
DRIVER'S JUNCTION BOX C
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FUSE 5
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
LKAS SWITCH
LT BLU WIRE
LT GRN WIRE
MILLIMETER WAVE RADAR
MULTIPURPOSE CAMERA UNIT
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Multipurpose camera circuit -> F-CAN H
Wiring diagram f-can h (9 of 12)
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BELT OUTER LAP TENSIONER
DRIVER'S SEAT POSITION SENSOR
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FRONT PASSENGER'S SEAT BELT OUTER LAP TENSIONER
FRONT PASSENGER'S SEAT BELT TENSIONER
FRONT PASSENGER'S WEIGHT SENSOR (FRONT INNER SIDE)
FRONT PASSENGER'S WEIGHT SENSOR (REAR INNER SIDE)
GAUGE CONTROL MODULE
GRN WIRE
LEFT SIDE CURTAIN AIR BAG INFLATOR
LT BLU WIRE
PNK WIRE
PPL
RED WIRE
SEAT BELT REMINDER IND
SELECTABLE ENERGY ABSORPTION DEVICE
SRS IND
TAN WIRE
W/ POWER SEAT
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (2 of 3) -> F-CAN H
Wiring diagram f-can h (10 of 12)
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CABLE REEL
CENTER CONSOLE
COMPUTER
COMPUTER DATA LINES SYSTEM
DATA LINES
ECON/ SPORT MODE/ EV SWITCH
F-CAN
F-CAN H
F-CAN L
FUSE 1
FUSE 21
FUSE 4
FUSE 6
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT W/
INTERIOR LIGHTS
LT BLU WIRE
LT GRN WIRE
PADDLE SHIFTER + (UPSHIFT SWITCH)
PADDLE SHIFTER - (DOWNSHIFT SWITCH)
PARK POSITION SENSOR
PCU
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
SBW SHIFTER CONTROL MODULE
SHIFT SOLENOID VALVE B
SYSTEM
TAN WIRE
TRANSCEIVER/
TRANSMISSION FLUID TEMPERATURE SENSOR
UNDER-DASH FUSE/RELAY BOX
WHT WIRE
YEL WIRE
Go to component -> Transmission circuit (2 of 2) -> F-CAN H
