Honda Insight ZE4 (2018-2024) automatic brake hold indicator Wiring diagrams
This page contains all the electrical diagrams for the component. automatic brake hold indicator, in which he is found in the car Honda Insight ZE4 (2018-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
automatic brake hold indicator wiring diagram (1 of 2)
ABS INDICATOR
APPLY SWITCH
AUTOMATIC BRAKE HOLD INDICATOR
AUTOMATIC BRAKE HOLD SWITCH
AUTOMATIC BRAKE HOLD SYSTEM INDICATOR
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRAKE LIGHT RELAY
BRAKE SYSTEM INDICATOR (AMBER)
BRAKE SYSTEM INDICATOR (RED) WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRIC PARKING BRAKE SWITCH
ELECTRIC PARKING BRAKE/AUTOMATIC BRAKE HOLD SWITCH (UNDER CENTER CONSOLE)
ELECTRIC SERVO BRAKE CONTROL UNIT/ PEDAL FEEL SIMULATOR
F-CAN
F-CAN H
F-CAN L
FUSE 21
FUSE 30
FUSE 34
FUSE 5
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PCM
PNK WIRE
PPL
RED WIRE
RELAY CIRCUIT BOARD UNDER-HOOD FUSE/RELAY BOX
RELAY ENERGIZED
RELEASE SWITCH
SAFETY SUPPORT/VSA OFF SWITCH
TAN WIRE
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX
VSA INDICATOR
VSA OFF INDICATOR
VSA OFF SWITCH
W/ SAFETY SUPPORT SWITCH/VSA OFF SWITCH
W/O SAFETY SUPPORT SWITCH/VSA OFF SWITCH
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> AUTOMATIC BRAKE HOLD INDICATOR
automatic brake hold indicator wiring diagram (2 of 2)
ABS INDICATOR
ANTI-LOCK BRAKES SYSTEM
AUTO HIGH-BEAM INDICATOR (GREEN)
AUTOMATIC BRAKE HOLD INDICATOR
AUTOMATIC BRAKE HOLD SYSTEM INDICATOR
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE SYSTEM INDICATOR (AMBER)
BRAKE SYSTEM INDICATOR (RED) WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DASHLIGHTS BRIGHTNESS CONTROL/TRIP SWITCH
ENCODER
ENGINE CONTROLS SYSTEM
EPS INDICATOR
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FOG LIGHT INDICATOR
FUEL GAUGE SENDING UNIT
FUEL TANK UNIT
FUSE 10
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HIGH BEAM INDICATOR
HOT AT ALL TIMES
ILLUMINATION CONTROL
LEFT TURN SIGNAL INDICATOR
LIGHTS ON INDICATOR
LIN TRANSCEIVER
LOW TIRE PRESSURE/ TPMS INDICATOR
LT GRN WIRE
MALFUNCTION INDICATOR LAMP (MIL)
NCA WIRE
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RIGHT TURN SIGNAL INDICATOR
SEAT BELT REMINDER INDICATOR
SECURITY INDICATOR
SOUND SYSTEMS
SPORT MODE/ECON/EV SWITCH
SRS INDICATOR
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
VSA INDICATOR
VSA OFF INDICATOR
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> AUTOMATIC BRAKE HOLD INDICATOR
