Honda Insight ZE2 facelift (2011-2014) dimming switch Wiring diagrams
This page contains all the electrical diagrams for the component. dimming switch, in which he is found in the car Honda Insight ZE2 facelift (2011-2014). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dimming switch (1 of 2)
BEEPER
BLK WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE FLUID LEVEL SWITCH (ON MASTER CYLINDER RESERVOIR)
BRAKE SYSTEM IND (AMBER)
BRIGHTENING SWITCH
CAN L
CHARGE/ ASSIST GAUGE
CHARGING SYSTEM IND
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUITS
COOLANT HIGH TEMPERATURE IND
DIMMING SWITCH
DISPLAY (MID) UNIT
DOOR OPEN IND
DRIVER'S DOOR SWITCH
FROM PIN 15 (DIAGRAM 1 OF 2)
FROM PIN 16 (DIAGRAM 1 OF 2)
FRONT PASSENGER'S DOOR SWITCH
FUEL GAUGE
FUEL GAUGE SENDING UNIT
FUEL TANK UNIT
FUEL TANK UNIT (ON TOP LEFT SIDE OF FUEL TANK)
GAUGE CONTROL MODULE (BEHIND INSTRUMENT CLUSTER)
GRN WIRE
GRY WIRE
HATCH LATCH SWITCH
HAZARD RELAY 2
HIGH BEAM IND
IMA SYSTEM IND
IMMOBILIZER SYSTEM IND
LCD
LEFT "C" PILLAR)
LEFT REAR DOOR SWITCH
LEFT TURN SIGNAL IND
LOW FUEL IND
LOW OIL PRESSURE IND
LOW TIRE PRESSURE IND
LT BLU WIRE
LT GRN WIRE
MPH/KMPH SWITCH
MULTI-INFORMATION
ODOMETER/TRIP METER/SELECT/ RESET SWITCH
OIL PRESSURE SWITCH
OIL PRESSURE SWITCH (LOWER LEFT SIDE OF ENGINE)
OPSW
ORG/ WIRE
PARKING BRAKE SWITCH
PARKING BRAKE SWITCH (BASE OF PARKING BRAKE LEVER)
PCM
PNK WIRE
RED WIRE
RIGHT REAR DOOR SWITCH
RIGHT TURN SIGNAL IND
SEAT BELT REMINDER IND
SECURITY IND
SEQUENTIAL SPORT SHIFT MODE SHIFT INDICATOR
SIDE AIR BAG CUTOFF IND
SOUNDER-
SPEEDOMETER
SPEEDOMETER (LCD)
SYSTEM MESSAGE IND
TACHOMETER
TO ILLUMINATION CONTROL, DIMMING CIRCUIT
TO ILLUMINATION CONTROL, DIMMING CIRCUIT (DIAGRAM 1 OF 2)
TPMS IND
TURN SIGNAL
VSA OFF SWITCH
VSA OFF SWITCH (IF EQUIPPED)
W/ PADDLE SHIFTERS
W/O PADDLE SHIFTERS
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> DIMMING SWITCH
Wiring diagram dimming switch (2 of 2)
+B BACKUP
A/T GEAR POSITION INDICATOR PANEL LIGHT
A/T GEAR POSITION INDICATOR PANEL LIGHT/PARK PIN SWITCH/SHIFT LOCK SOLENOID
AUDIO REMOTE SWITCH
AUDIO UNIT (W/O NAVIGATION) AUDIO- NAVIGATION UNIT (W/ NAVIGATION)
B-CAN
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRIGHTENING SWITCH
CABLE REEL (TOP OF STEERING COLUMN)
CLIMATE CONTROL UNIT (BEHIND MIDDLE OF DASH)
COMBI GND OFF (LIGHT)
COMBI H/L GND
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUITS
CRUISE CONTROL COMBINATION SWITCH
DIMMING SWITCH
ECON SWITCH
FRONT PASSENGER'S AIRBAG CUT-OFF INDICATOR
FUSE 1
FUSE 22
FUSE 29
GAUGE CONTROL MODULE
GLOVE BOX LIGHT (IF EQUIPPED)
GRN WIRE
GRY WIRE
H/L ON LT SW SW SW
H/L SMALL
H/L SMALL OFF ON LT (LIGHT) SW SW SW
HAZARD WARNING SWITCH
HEAD
HEAD OFF
HEAD OFF PARK
HEADLIGHT SWITCH
HFL-VOICE CONTROL SWITCH (W/ NAVIGATION) HFL-SWITCH (W/O NAVIGATION)
HOT AT ALL TIMES
HOT IN ON OR START
ILL ILL
LT BLU WIRE
LX, EX
LX, EX DX
METER
MICU
MIDDLE OF DASH)
MULTI- INFORMATION SWITCH
MULTI-INFORMATION SWITCH STEERING WHEEL
OFF
OFF PARK
P-GND
P-GND S-GND
PARK
PNK 16 15 WIRE
PNK WIRE
POWER MIRROR SWITCH
RED WIRE
RED/BLK WIRE
S GND
STEERING WHEEL)
TAILLIGHT RELAY
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
VSA OFF SWITCH
W/ CRUISE CONTROL
W/O CRUISE CONTROL
WHT WIRE
Go to component -> Instrument illumination circuit -> DIMMING SWITCH
