Honda Insight ZE2 (2009-2011) vsa off ind fog light ind Wiring diagram
This page shows the only wiring diagram for the component.vsa off ind fog light ind, which is found in the car Honda Insight ZE2 (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vsa off ind fog light ind (1 of 1)
+B BACKUP
ABS IND CRUISE CONTROL IND
AUTO STOP IND
B-CAN TRANSCEIVER
BACKGROUND
BLK WIRE
BLU WIRE
BLU/WHT WIRE
BRAKE SYSTEM IND CRUISE CONTROL MAIN SWITCH IND
CABLE REEL
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUITS
COOLANT LOW TEMPERATURE IND
CRUISE CONTROL SYSTEM
DOOR DOOR DOOR DOOR SW SW SW SW (DR) (RD) (AS)
ECON SWITCH
EPS IND
F-CAN TRANSCEIVER
FUSE 1
FUSE 22
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
ILLUMINATION CONTROL, DIMMING CIRCUIT
LCD
LIGHTS ON IND
LT BLU WIRE
LT GRN WIRE
METER
MICU
MIL IND
MULTI- INFORMATION SWITCH
NAVIGATION SYSTEM
NEXT SWITCH
ORG/ WIRE
PNK WIRE
POINTER DIAL,
PPL
RED WIRE
RED/BLK WIRE
SELECT/ PREVIOUS RESET SWITCH SWITCH
SRS IND
STEERING WHEEL)
T/G (RA) SW
TO SECURITY IND (DIAGRAM 2 OF 2)
TO SIDE AIR BAG CUTOFF IND (DIAGRAM 2 OF 2)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
VSA MALFUNCTION/ ECO IND ACTIVATION IND
VSA OFF IND FOG LIGHT IND
W/ CRUISE CONTROL
WARNING SYSTEMS
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component: -> Instrument cluster circuit (1 of 2) -> VSA OFF IND FOG LIGHT IND
