Honda Insight ZE2 (2009-2011) transmission range switch (on transaxle Wiring diagram
This page shows the only wiring diagram for the component.transmission range switch (on transaxle, which is found in the car Honda Insight ZE2 (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission range switch (on transaxle (1 of 1)
APP SENSOR (LEFT SIDE OF DASH)
APSA
BKSW BKSWNC PPL MRLY ETCSRLY
BLK WIRE
BLU WIRE
BLU/YEL WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CANH CANL NDN ATPFWD PPL APSB
COMPUTER DATA LINES SYSTEM
CVT OUTPUT SHAFT (DRIVEN PULLEY) SPEED SENSOR (ON TRANSAXLE HOUSING)
ETCSM- ETCSM+ TPSA TPSB
FUSE 12
FUSE 24
GRN WIRE
HORN RELAY
HOT AT ALL TIMES
HOT IN ON OR START
HOUSING)
IDLE STOP SWITCH (UNDER LEFT SIDE OF DASH)
LT BLU WIRE
LT GRN WIRE
MICU
ORG/ WIRE
PCM (LEFT FRONT OF ENGINE COMPT)
PPL
PPL 2 3 4
RED WIRE
RED/BLK WIRE
TP SENSOR/ THROTTLE ACTUATOR (REAR OF ENGINE)
TRANSMISSION RANGE SWITCH (ON TRANSAXLE
TRANSMISSION RANGE SWITCH (ON TRANSAXLE HOUSING)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
W/ PADDLE SHIFTERS
W/O PADDLE SHIFTERS
WHT WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component: -> Cruise control circuit (1 of 2) -> TRANSMISSION RANGE SWITCH (ON TRANSAXLE
