Honda Insight ZE2 (2009-2011) navig- navig- ation ation back talk switch switch Wiring diagram
This page shows the only wiring diagram for the component.navig- navig- ation ation back talk switch switch, which is found in the car Honda Insight ZE2 (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram navig- navig- ation ation back talk switch switch (1 of 1)
+B BACKUP
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 GND HFL STRG SW HFL MUTE
1 2 MIC+ MIC- PNK WIRE
AUDIO-NAVIGATION UNIT (BEHIND MIDDLE OF DASH)
B-CAN HFL ICON
BLK WIRE
BLU WIRE
BLUETOOTH TRANSCEIVER
BRN WIRE
CABLE REEL
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 14
GRN WIRE
GRY WIRE
HANDSFREELINK CONTROL UNIT (RIGHT SIDE OF DASH)
HFL BACK SWITCH
HFL COMM SH
HFL ICON
HFL MUTE
HFL TALK SWITCH
HFL-NAVIGATION MICROPHONE
HFL-VOICE CONTROL SWITCH
HOT AT ALL TIMES
HOT IN ACC OR ON
LT BLU WIRE
LT GRN WIRE
MICU
NAVI COMM SH
NAVIG- NAVIG- ATION ATION BACK TALK SWITCH SWITCH
ORG/ WIRE
ORG/WHT WIRE
PNK PNK PPL WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RED/BLK WIRE
SOUND SYSTEMS
STEERING WHEEL)
TELM SIG -
TELM SIG - TELM SIG SH MIC SIG+ MIC SIG-
TELM SIG - TELM SIG SH MIC SIG+ MIC SIG- MIC SH
TELM SIG+ MIC SH MIC+ MIC- +B
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Hands free module circuit, except honda accessory -> NAVIG- NAVIG- ATION ATION BACK TALK SWITCH SWITCH
