Honda Insight ZE2 (2009-2011) maf/iat idle stop sensor switch wiring diagram
This page shows the only wiring diagram for the component.maf/iat idle stop sensor switch, which is found in the car Honda Insight ZE2 (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
maf/iat idle stop sensor switch wiring diagram (1 of 1)
A/T GEAR POSITION INDICATOR PANEL LIGHT/PARK PIN SWITCH/SHIFT LOCK SOLENOID
ABS MODULATOR CONTROL UNIT (W/O VSA) VSA MODULATOR CONTROL UNIT (W/ VSA)
AUXILIARY UNDER-HOOD FUSE/RELAY BOX (LEFT FRONT OF ENGINE COMPT)
BACK LT-
BLK/RED WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/YEL WIRE
BRN WIRE
EPS CONTROL UNIT
EVAP CANISTER PURGE VALVE
FROM FUSE 12 (DIAGRAM 4 OF 5) FUSE
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 2 OF 5)
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUSE
FUSE FUSE FUSE
GRN WIRE
GRN/RED WIRE
IGNITION SWITCH
IMA
J/C
LOCK
LT BLU WIRE
LT GRN WIRE
MAF/IAT IDLE STOP SENSOR SWITCH
MCM
MICU
MICU ABS/VSA
MICU OPDS
MICU SRS
ORG/ WIRE
PCM
PGM-FI MAIN RELAY 2
PPL
PUMP WASHER WIPER METER
REAR WINDOW WIPER MOTOR
RED WIRE
SECONDARY
SHIFT LOCK SOLENOID
SRS UNIT ODS UNIT
SRS UNIT PCM
TO FUSE 16 (DIAGRAM 4 OF 5)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 5 OF 5)
TPMS CONTROL UNIT (IF EQUIPPED)
UNDER-DASH FUSE/RELAY BOX
VBSOL
WHT WIRE
WIPER
YAW RATE LATERAL DC-DC ACCELERATION CONVERTER SENSOR (W/ VSA)
YEL WIRE
YEL/BLK WIRE
Go to component -> Power distribution circuit (4 of 5) -> MAF/IAT IDLE STOP SENSOR SWITCH
