Honda Insight ZE2 (2009-2011) left/ right motor up/ down motor defogger Wiring diagram

This page shows the only wiring diagram for the component.left/ right motor up/ down motor defogger, which is found in the car Honda Insight ZE2 (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left/ right motor up/ down motor defogger (1 of 1)

Wiring diagram left/ right motor up/ down motor defogger for Honda Insight ZE2 (2009-2011)

Get access

BLK WIRE BLU WIRE BRN WIRE DEFOGGER SYSTEM DOWN/ LEFT UP/ RIGHT DOWN/ RIGHT UP/ LEFT FUSE 10 GRY WIRE HOT IN ON LEFT POWER MIRROR UP/ DOWN MOTOR LEFT/ RIGHT MOTOR UP/ DOWN MOTOR DEFOGGER LT GRN WIRE MICU HAC ORG/ WIRE POWER MIRROR SWITCH POWER MIRROR SWITCH LIGHT RED WIRE RIGHT LEFT RIGHT POWER MIRROR LEFT/ RIGHT MOTOR DEFOGGER SWITCH 1 SWITCH 2 SWITCH 3 UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) UP LEFT DOWN RIGHT W/O SIDE TURN SIGNALS W/ SIDE TURN SIGNALS WHT WIRE YEL WIRE

Go to component: -> Power mirrors circuit -> LEFT/ RIGHT MOTOR UP/ DOWN MOTOR DEFOGGER
