Honda Insight ZE2 (2009-2011) knock sensor (left side wiring diagram
This page shows the only wiring diagram for the component.knock sensor (left side, which is found in the car Honda Insight ZE2 (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
knock sensor (left side wiring diagram (1 of 1)
AFS+ AFS- CMP CKP POILCSA
AFSHTC
AUXILIARY FUSE 1 UNDER-HOOD FUSE/RELAY BOX (LEFT FRONT OF ENGINE COMPT)
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BRN BLK/WHT WIRE
BRN WIRE
BRN/YEL WIRE
EXHAUST SIDE IGNITION COILS (TOP RIGHT OF ENGINE)
FROM ETCS CONTROL RELAY (DIAGRAM 4 OF 5)
FUSE 2
FUSE 33
FUSE 39
GRN WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
ICM
ICM ICM
IGNITION COIL RELAY
IGRTNE
INTAKE SIDE IGNITION COILS (TOP CENTER OF ENGINE)
J/C
KNOCK SENSOR (LEFT SIDE
MAP
OF ENGINE)
PCM (LEFT FRONT OF ENGINE COMPT)
PGM-FI MAIN RELAY 1
PGMETCS ETCSM- ETCSM+
PPL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
TPSA TPSB POILCSB
UNDER-DASH FUSE/ RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK BLU WIRE
YEL/BLK BRN WIRE
YEL/BLK RED WIRE
YEL/BLK WIRE
YEL/BLK YEL WIRE
YEL/RED WIRE
Go to component -> Wiring diagram engine performance 1.3l, engine controls circuit (5 of 5) -> KNOCK SENSOR (LEFT SIDE
