Honda Insight ZE2 (2009-2011) fast controller area network transceiver Wiring diagram
This page shows the only wiring diagram for the component.fast controller area network transceiver, which is found in the car Honda Insight ZE2 (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fast controller area network transceiver (1 of 1)
4 3 PPL
BATTERY TERMINAL FUSE BOX (TOP OF BATTERY)
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CAN-H CAN-L NEP
CAN-L CAN-H
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUITS
ENGINE COMPT)
EPS CONTROL UNIT (LEFT SIDE OF DASH)
EPS IND
EPS MOTOR
EPS TORQUE SENSOR
FAST CONTROLLER AREA NETWORK TRANSCEIVER
FUSE 11
FUSE 2
FUSE 22
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
K LINE
LT BLU WIRE
M- M+
MICU
NEP PPL
PCM (LEFT FRONT OF ENGINE COMPT)
PG +B
PPL
PPL T/S GND
RED WIRE
SCS
STEERING GEARBOX (LEFT REAR OF
STEERING GEARBOX CONNECTOR
T/S GND PNK WIRE
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
WHT/GRN WIRE
YEL WIRE
Go to component: -> Electronic power steering circuit -> FAST CONTROLLER AREA NETWORK TRANSCEIVER
