Honda Insight ZE2 (2009-2011) +b acs backup Wiring diagram

+B ACS BACKUP A/F SENSOR RELAY AC-CLK AC-SO AC-SI ACS MODE 1 MODE 2 MODE 3 MODE 4 AC-SI AC-SO AC-CLK BLW-G PNK WIRE AIR MIX CONTROL MOTOR (BEHIND GLOVE BOX) AMD-P AMD-P B-CAN RR DEF RLY REC FRS M-DEF M-VENT M-HOT M-COOL GND AUDIO- NAVIGATION UNIT (W/ NAVIGATION) (BEHIND MIDDLE OF DASH) BLK WIRE BLOWER MOTOR BLOWER MOTOR RELAY BLU WIRE BLW-V BRN WIRE CLIMATE CONTROL UNIT (BEHIND MIDDLE OF DASH) COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM EVAPORATOR TEMPERATURE SENSOR (BEHIND GLOVE BOX) FRS REC FUSE 1 FUSE 10 FUSE 22 FUSE 26 FUSE 30 FUSE 31 FUSE 43 FUSE 47 FUSE 57 GRN WIRE GRY WIRE HAC B-CAN HOT AT ALL TIMES HOT IN ON HOT IN ON OR START ILL+ TSUM TR PPL LT BLU WIRE LT GRN WIRE M-COOL M-DEF M-HOT M-VENT METER MICU MIRRORS SYSTEM MODE 1 MODE 2 MODE 3 MODE 4 MODE CONTROL MOTOR (UNDER CENTER OF DASH) ORG/ WIRE OUTSIDE AIR TEMPERATURE SENSOR (BEHIND RIGHT SIDE OF FRONT BUMPER) PNK TAM TEVA HUM WIRE PNK WIRE PPL RECIRCULATION CONTROL MOTOR (BEHIND GLOVE BOX) RED WIRE S-COM SUNLIGHT SENSOR (TOP RIGHT OF DASH) UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) WHT WIRE YEL WIRE
