Car Wiring Diagrams for Instrument illumination circuit for Honda Insight ZE1 (1999-2006)

AUDIO UNIT BLK WIRE CLIMATE CONTROL UNIT HEATER CONTROL PANEL DASH LIGHTS BRIGHTNESS CONTROLLER DRIVING CIRCUIT FUEL CONSUMPTION DISPLAY SELECT SWITCH FUSE 6 GAUGE ASSEMBLY GAUGE LIGHTS (2) GAUGE LIGHTS (5) HAZARD SWITCH HOT IN HEAD OR PARK HOT IN ON OR START PARK PIN SWITCH (CVT) POWER WINDOW MASTER SWITCH RED WIRE RED/BLK WIRE UNDER-DASH FUSE/ RELAY BOX (LEFT END OF DASH) FUSE 15 YEL WIRE
