Honda Insight ZE1 (1999-2006) pnk atp d atp np atp r wiring diagram

ATP L BLK WIRE BLK/BLU WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE PEDAL POSITION SWITCH (UNDER LEFT SIDE OF DASH) BRN WIRE BRN/BLK WIRE CABLE REEL CAS SOLENOID VALVES A, B (RIGHT SIDE OF ENGINE COMPT) CONN A CONN B CVT DRIVE PULLEY SPEED SENSOR (FRONT TOP OF TRANS- MISSION) CVT DRIVEN PULLEY SPEED SENSOR (MIDDLE OF ENGINE) CVT PULLEY PRESSURE CONTROL VALVE CVT SPEED CHANGE CONTROL VALVE CVT SPEED SENSOR (MIDDLE OF ENGINE) CVT START CLUTCH PRESSURE CONTROL VALVE DATALINK CONNECTOR (BEHIND CENTER OF DASH) DRIVING MODE BUTTONS (IN STEERING WHEEL) ENGINE CONTROL MODULE (RIGHT SIDE OF FLOOR) ENGINE COOLANT TEMPERATURE SENSOR (REAR OF ENGINE) EXTERIOR LIGHTS SYSTEM (BACKUP LAMPS) FUSE 18 FUSE 4 FUSE 6 GAUGE ASSEMBLY GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START INH SOL MAP PB INHIBITOR SOLENOID (ON VALVE BODY) INTAKE AIR TEMPERATURE SENSOR (ON AIR INTAKE HOSE) J/C LT BLU WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE NEP NON-SAE TERMINAL NUMBERS (USED IN SERVICE MANUAL) P/N NEP TMB TMA PNK ATP D ATP NP ATP R WIRE PNK PNK WIRE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE SAE TERMINAL NUMBERS SC LS+ DN LS+ DR LS+ SPO IND ECT D IND SPO SW SPO MODE TEST TACH CONNECTOR (LEFT REAR OF ENG COMPT) THROTTLE POSITION SENSOR (ON THROTTLE BODY) TPS ECT IAT VSS MAP TRANSMISSION CONTROL MODULE (UNDER RIGHT SIDE OF KICK PANEL) TRANSMISSION RANGE SWITCH UNDER- DASH FUSE/ RELAY BOX (AT LEFT END OF DASH) UNDER- HOOD FUSE/ RELAY BOX (LEFT SIDE OF ENGINE DASH) VBU D SW VREF WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE
