Honda Insight ZE1 (1999-2006) gauge assembly Wiring diagrams

This page contains all the electrical diagrams for the component. gauge assembly, in which he is found in the car Honda Insight ZE1 (1999-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram gauge assembly (21 of 22)

Wiring diagram gauge assembly for Honda Insight ZE1 (1999-2006)

Get access

BLK WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE FUSE 18 FUSE 3 FUSE 6 GAUGE ASSEMBLY GRN WIRE GRN/BLK WIRE GRN/RED WIRE HI LO HOT AT ALL TIMES HOT IN ON OR START INTERMITTENT WIPER DRIVING CIRCUIT INTERMITTENT WIPER RELAY (AT LEFT FRONT OF ENGINE COMPT) LCD DISPLAY MIST MIST HI OFF LO INT OFF OFF LO INT PARK RED WIRE RUN WIRE UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) VOLTAGE FEED WASH WHT WIRE WHT/BLK WIRE WHT/RED WIRE WINDSHIELD WASHER MOTOR (AT RIGHT FRONT OF ENGINE COMPT) WINDSHIELD WIPER MOTOR (AT RIGHT REAR OF ENGINE COMPT) WINDSHIELD WIPER/WASHER SWITCH WIPER/WASHER SWITCH YEL WIRE

Go to component: -> Front washer/wiper circuit -> GAUGE ASSEMBLY

Wiring diagram gauge assembly (22 of 22)

Wiring diagram gauge assembly for Honda Insight ZE1 (1999-2006)

Get access

BEEPER BLK WIRE BLU/RED WIRE BLU/WHT WIRE DOOR INDICATOR DRIVER'S DOOR SWITCH DRIVER'S SEAT BELT SWITCH DRIVING CIRCUIT FUSE 15 FUSE 18 FUSE 6 GAUGE ASSEMBLY GRN/ORG WIRE HOT AT ALL TIMES HOT IN RUN OR START HOT W/ HEADLIGHT SWITCH IN HEAD OR PARK IGNITION KEY SWITCH KEYLESS DOOR LOCK CONTROL UNIT (UNDER LEFT SIDE OF DASH) LCD DISPLAY ODO/TRIP SWITCH MPH/KM/H SWITCH RED/BLK WIRE RED/BLU WIRE SEAT BELT REMINDER LIGHT UNDERDASH FUSE/RELAY BOX (BEHIND LEFT END OF DASH) VOLTAGE FEED WHT/RED WIRE YEL WIRE

Go to component: -> Warning systems circuit -> GAUGE ASSEMBLY
