Manual a/c circuit for Honda HR-V II (2015-2018)

32 BIT MICROPROCESSOR B-CAN L B-CAN H B-CAN TRANSCEIVER BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM FUSE 24 FUSE 34 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HEATER CONTROL PANEL HOT IN ON HOT IN ON OR START HVAC CONTROL UNIT ILLUMINATION CONTROL LT BLU WIRE LT GRN WIRE MICU OUTSIDE AIR TEMPERATURE SENSOR PNK WIRE PPL RECIRCULATION CONTROL MOTOR RED WIRE REGULATOR UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

A/C COMPRESSOR A/C COMPRESSOR CLUTCH A/C COMPRESSOR CLUTCH RELAY AUXILIARY UNDER-DASH FUSE BOX A AUXILIARY UNDER-DASH RELAY HOLDER B AUXILIARY UNDER-HOOD RELAY BOX A BLK WIRE BLOWER MOTOR BLOWER MOTOR RELAY BLOWER RESISTOR BLU WIRE FUSE 14 FUSE 2-4 GRN WIRE HEATER FAN SWITCH HOT AT ALL TIMES LT BLU WIRE OFF ORG/ WIRE PNK WIRE PPL RED WIRE TAN WIRE THERMAL PROTECTOR WHT WIRE YEL WIRE

A/C CONDENSER FAN MOTOR A/C CONDENSER FAN RELAY A/C PRESSURE SENSOR BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ECT SENSOR 2 ENGINE CONTROLS SYSTEM ETCS CONTROL RELAY EVAPORATOR TEMPERATURE SENSOR FAN CONTROL RELAY FUSE 12 FUSE 14 FUSE 23 FUSE 31 FUSE 4 GRN WIRE GRY WIRE HOT AT ALL TIMES LT BLU WIRE LT GRN WIRE PCM (LEFT SIDE OF ENGINE COMPT) PNK WIRE PPL RADIATOR FAN MOTOR RADIATOR FAN RELAY RED WIRE UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE
