Honda HR-V II (2015-2018) windshield washer motor relay circuit Wiring diagram
This page shows the only wiring diagram for the component.windshield washer motor relay circuit, which is found in the car Honda HR-V II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram windshield washer motor relay circuit (1 of 1)
A/T GEAR POSITION INDICATOR
AUXILIARY UNDER-DASH RELAY HOLDER A
BACKUP LIGHT SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
CVT
FUSE 22
FUSE 23
FUSE 35
FUSE 40
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
LT BLU WIRE
M/T
MICU
OFF
PCM
PNK WIRE
PPL
PPL M/T
REAR WINDOW WASHER MOTOR RELAY CIRCUIT
REAR WINDOW WIPER MOTOR
REAR WIPER/ WASHER SWITCH
RED WIRE
TAN WIRE
TRANSMISSION RANGE SWITCH
UNDER- DASH FUSE/ RELAY BOX
W/ KEYLESS ACCESS SYSTEM W/O KEYLESS ACCESS SYSTEM
WASH
WINDSHIELD WASHER MOTOR RELAY CIRCUIT
WINDSHIELD/ REAR WINDOW WASHER MOTOR
WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Rear wiper/washer circuit -> WINDSHIELD WASHER MOTOR RELAY CIRCUIT
