Honda HR-V II (2015-2018) rear window defogger switch/ power mirror defogger switch ind Wiring diagram
This page shows the only wiring diagram for the component.rear window defogger switch/ power mirror defogger switch ind, which is found in the car Honda HR-V II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear window defogger switch/ power mirror defogger switch ind (1 of 1)
32 BIT MICROPROCESSOR
AIR MIX CONTROL MOTOR
B-CAN L B-CAN H
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATE CONTROL UNIT
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DIMMING CIRCUIT
DRIVER'S AIR MIX CONTROL UNIT
DUAL A/C SINGLE A/C
ECON IND
EVAPORATOR TEMPERATURE SENSOR
FUSE 24
FUSE 34
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT IN ON
HOT IN ON OR START
ILLUMINATION CONTROL
LT BLU WIRE
LT GRN WIRE
MODE CONTROL MOTOR
ORG/ WIRE
OUTSIDE AIR TEMPERATURE SENSOR
PASSENGER'S AIR MIX CONTROL MOTOR
PNK WIRE
PPL
REAR WINDOW DEFOGGER SWITCH/ POWER MIRROR DEFOGGER SWITCH
REAR WINDOW DEFOGGER SWITCH/ POWER MIRROR DEFOGGER SWITCH IND
RED WIRE
STABILIZING CIRCUIT
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
WARNING DRIVING CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (1 of 3) -> REAR WINDOW DEFOGGER SWITCH/ POWER MIRROR DEFOGGER SWITCH IND
