Honda HR-V II (2015-2018) front passenger's door outer handle touch sensor/ lock switch/ lf antenna Wiring diagram
This page shows the only wiring diagram for the component.front passenger's door outer handle touch sensor/ lock switch/ lf antenna, which is found in the car Honda HR-V II (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's door outer handle touch sensor/ lock switch/ lf antenna (1 of 1)
