Honda HR-V II (2015-2018) driver's door outer handle touch sensor/lock switch/ lf antenna Wiring diagrams
This page contains all the electrical diagrams for the component. driver's door outer handle touch sensor/lock switch/ lf antenna, in which he is found in the car Honda HR-V II (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
driver's door outer handle touch sensor/lock switch/ lf antenna wiring diagram (1 of 2)
A/T GEAR POSITION INDICATOR
ACC RELAY
AUXILIARY UNDER-DASH FUSE BOX A
AUXILIARY UNDER-DASH RELAY HOLDER A
BLK WIRE
BLU WIRE
BRN WIRE
CLUTCH PEDAL POSITION SWITCH
COMPUTER DATA LINES SYSTEM
CVT
DOOR LF ANTENNA
DRIVER'S DOOR OUTER HANDLE TOUCH SENSOR/LOCK SWITCH/ LF ANTENNA
FRONT PASSENGER'S DOOR OUTER HANDLE TOUCH SENSOR/LOCK SWITCH/ LF ANTENNA
FUSE 1-2
FUSE 1-3
FUSE 2-3
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LOCK SWITCH
LT BLU WIRE
LT GRN WIRE
M/T
PCM
PNK WIRE
PPL
RED WIRE
TOUCH SENSOR
TRANSMISSION RANGE SWITCH
WHT WIRE
YEL WIRE
Go to component -> Forced entry circuit (2 of 6) -> DRIVER'S DOOR OUTER HANDLE TOUCH SENSOR/LOCK SWITCH/ LF ANTENNA
