Immobilizer circuit for Honda Fit I (2004-2009)

1 2 3 4 5 6 7 SENS GND IMOCD DIAG-H H-BRK SW IMOARM BLK WIRE BLK/YEL WIRE BRN/YEL WIRE CONTROLLER AREA NETWORK CONTROLLER DLC (UNDER LEFT SIDE OF DASH) ECM/PCM (UNDER RIGHT SIDE OF DASH) ENGINE CONTROLS SYSTEM FUEL PUMP FUEL TANK UNIT (IN FUEL TANK) FUSE 11 FUSE 14 FUSE 8 GAUGE CONTROL MODULE GRN/ORG WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGN IN RLY CTRL PWR IN PWR IN FUEL PUMP CTRL IMMO CODE IN IMMOBILIZER CONTROL UNIT-RECEIVER (UNDER STEERING WHEEL COVER) IMMOBILIZER SYSTEM INDICATOR LT GRN/BLK WIRE PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE LEVER) PGM-FI MAIN RELAY 1 PGM-FI MAIN RELAY 2 RED/BLK WIRE RED/YEL WIRE UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH, RIGHT OF STEERING COLUMN) UNDER-HOOD FUSE/RELAY BOX (AT LEFT REAR OF ENGINE COMPT) WHT/RED WIRE YEL/BLK WIRE YEL/GRN WIRE
