Honda Fit I (2004-2009) tailgate latch switch Wiring diagram
This page shows the only wiring diagram for the component.tailgate latch switch, which is found in the car Honda Fit I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tailgate latch switch (1 of 1)
A/C SWITCH (USA: FIT, FIT SPORT) (CANADA: LX, SPORT)
ACCESSORY POWER SOCKET
BLK WIRE
BLOWER SWITCH
CABLE REEL
CRUISE CONTROL COMBINATION SWITCH
DLC
DRIVER'S SEAT BELT SWITCH
FRONT PASSENGER'S SEAT BELT SWITCH
FUEL TANK UNIT
HIGH MOUNT BRAKE LIGHT
LEFT BACK-UP LIGHT
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
ODS UNIT
REAR REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER
REAR WINDOW WIPER MOTOR
RELAY
RIGHT BACK-UP LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT LICENSE PLATE LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
STEERING WHEEL UPSHIFT (+) SWITCH
SWITCH
SWITCH (CANADA: DX) REAR WINDOW DEFOGGER SWITCH,
TAILGATE LATCH SWITCH
WIPER/ WASHER
Go to component: -> Ground distribution circuit (3 of 3) -> TAILGATE LATCH SWITCH
