Car Wiring Diagrams for Radio circuit, w/o navigation w/ display audio for Honda Fit GR (2019-2022)

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 34 FUSE 37 GPS ANTENNA GRN WIRE GRY WIRE HOT IN ON OR ACC HOT IN ON OR START LT BLU WIRE LT GRN WIRE MICU NAVIGATION SYSTEM NCA WIRE PNK WIRE PPL RED WIRE ROOF ANTENNA UNDER- DASH FUSE/ RELAY BOX W/ XM WHT WIRE YEL WIRE

32 BIT MICROPROCESSOR BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM F-CAN H F-CAN L F-CAN TRANSCEIVER FRONT PASSENGER'S DOOR SPEAKER FUSE 21 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES LT GRN WIRE PARKING BRAKE SWITCH PNK WIRE PPL RED WIRE RIGHT TWEETER TAN WIRE TOP OF TRANSMISSION) TRANSMISSION RANGE SWITCH UNDER-HOOD FUSE/RELAY BOX WHT WIRE

AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH AUDIO UNIT/ AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CABLE REEL CH- COMPUTER DATA LINES SYSTEM DISP CHANGE DRIVER'S DOOR SPEAKER GRN WIRE GRY WIRE HANG-UP BACK SWITCH HFL SWITCH LEFT REAR DOOR SPEAKER LEFT TWEETER MENU MOONROOF MOTOR/ CONTROL UNIT NAVIGATION SYSTEM NCA WIRE OPTION CONNECTOR (FOR USB PORT A) OPTION CONNECTOR (FOR USB PORT B) PCM PICK-UP SWITCH PNK WIRE PPL RED WIRE RIGHT REAR DOOR SPEAKER SOURCE TALK SWITCH VOL DOWN VOL UP W/ MOONROOF WHT WIRE YEL WIRE
