Car Wiring Diagrams for Navigation circuit for Honda Fit GR (2019-2022)

AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FRONT PASSENGER'S DOOR SPEAKER FUSE 34 FUSE 37 GPS ANTENNA GRN WIRE GRY WIRE HOT W/ ACCESSORY RELAY ENERGIZED LT BLU WIRE LT GRN WIRE MICU NAVIGATION SYSTEM NAVIGATION SYSTEM (REAR CAMERA CIRCUIT) NCA WIRE PNK WIRE PPL RED WIRE RELAY ENERGIZED RIGHT TWEETER ROOF ANTENNA UNDER- DASH FUSE/ RELAY BOX WHT WIRE YEL WIRE

32 BIT MICROPROCESSOR BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SPEAKER F-CAN H F-CAN L F-CAN TRANSCEIVER FUSE 21 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES KEYLESS ACCESS CONTROL UNIT LEFT REAR DOOR SPEAKER LEFT TWEETER LT GRN WIRE MOONROOF MOTOR/ CONTROL UNIT NCA WIRE PARKING BRAKE SWITCH PCM PNK WIRE PPL RED WIRE RIGHT REAR DOOR SPEAKER TAN WIRE TOP OF TRANSMISSION) TRANSMISSION RANGE SWITCH UNDER-HOOD FUSE/RELAY BOX WHT WIRE

AUDIO REMOTE/MULTI-INFORMATION DISPLAY SWITCH AUDIO UNIT/AUDIO NAVIGATION UNIT BLK WIRE BLU WIRE BRN WIRE CABLE REEL CH- COMPUTER DATA LINES SYSTEM DISP CHANGE GRN WIRE GRY WIRE HANG-UP BACK SWITCH HFL SWITCH MENU NAVIGATION SYSTEM NAVIGATION SYSTEM (LANE WATCH CAMERA CIRCUIT) NCA WIRE OPTION CONNECTOR (FOR USB PORT A) OPTION CONNECTOR (FOR USB PORT B) PICK-UP SWITCH PNK WIRE PPL RED WIRE SOURCE TALK SWITCH VOL DOWN VOL UP WHT WIRE YEL WIRE
