Honda Fit GR (2019-2022) w/ climate control w/o climate control w/ power mirror defogger Wiring diagram
This page shows the only wiring diagram for the component.w/ climate control w/o climate control w/ power mirror defogger, which is found in the car Honda Fit GR (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ climate control w/o climate control w/ power mirror defogger (1 of 1)
AUXILIARY UNDER-DASH FUSE BOX
AUXILIARY UNDER-HOOD RELAY BOX A
BLK WIRE
BRN WIRE
CLIMATE CONTROL UNIT
FUSE 11
FUSE 13
FUSE 24
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
IND
LEFT POWER MIRROR
LT BLU WIRE
MICU
PNK PNK WIRE
PNK WIRE
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
REAR WINDOW DEFOGGER SWITCH
REAR WINDOW DEFOGGER SWITCH INDICATOR
RIGHT POWER MIRROR
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
W/ CLIMATE CONTROL W/O CLIMATE CONTROL W/ POWER MIRROR DEFOGGER
YEL WIRE
Go to component -> Defoggers circuit -> W/ CLIMATE CONTROL W/O CLIMATE CONTROL W/ POWER MIRROR DEFOGGER
