Honda Fit GR (2019-2022) sunlight sensor/automatic lighting control unit-sensor Wiring diagrams

This page contains all the electrical diagrams for the component. sunlight sensor/automatic lighting control unit-sensor, in which he is found in the car Honda Fit GR (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram sunlight sensor/automatic lighting control unit-sensor (1 of 3)

Wiring diagram sunlight sensor/automatic lighting control unit-sensor for Honda Fit GR (2019-2022) (1 of 3)

Get access

BLK WIRE BLU WIRE DATA LINK CONNECTOR (DLC) FUSE 34 HOT IN ON OR START IMMOBILIZER KEYLESS CONTROL UNIT KEYLESS ACCESS CONTROL UNIT (BEHIND INSTRUMENT CLUSTER) LT BLU WIRE LT GRN WIRE MICU ORG/ WIRE PNK WIRE RED WIRE SRS UNIT SUNLIGHT SENSOR/AUTOMATIC LIGHTING CONTROL UNIT-SENSOR UNDER-DASH FUSE/RELAY BOX W/ KEYLESS ACCESS W/O KEYLESS ACCESS WHT WIRE YEL WIRE

Go to component -> Computer data lines circuit, w/ can gateway (1 of 3) -> SUNLIGHT SENSOR/AUTOMATIC LIGHTING CONTROL UNIT-SENSOR

Wiring diagram sunlight sensor/automatic lighting control unit-sensor (2 of 3)

Wiring diagram sunlight sensor/automatic lighting control unit-sensor for Honda Fit GR (2019-2022) (2 of 3)

Get access

AUDIO UNIT/ AUDIO NAVIGATION UNIT BLU WIRE GAUGE CONTROL MODULE IMMOBILIZER KEYLESS CONTROL UNIT LT BLU WIRE PNK WIRE RED WIRE SUNLIGHT SENSOR/AUTOMATIC LIGHTING CONTROL UNIT-SENSOR WHT WIRE

Go to component -> Computer data lines circuit, w/o can gateway (2 of 2) -> SUNLIGHT SENSOR/AUTOMATIC LIGHTING CONTROL UNIT-SENSOR

Wiring diagram sunlight sensor/automatic lighting control unit-sensor (3 of 3)

Wiring diagram sunlight sensor/automatic lighting control unit-sensor for Honda Fit GR (2019-2022) (3 of 3)

Get access

0) OFF 1) PARK 2) AUTO 3) HEAD AUXILIARY UNDER-DASH FUSE BOX AUXILIARY UNDER-HOOD RELAY BOX A BLK WIRE BLU WIRE BRN WIRE COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM FUSE 34 FUSE 9 GRN WIRE GRY WIRE HAZARD WARNING SWITCH HEADLIGHT SWITCH HOT AT ALL TIMES HOT IN ON OR START LT GRN WIRE MICU MODE CONTROL SWITCH MOONROOF SWITCH PARK PIN SWITCH/ SHIFT LOCK SOLENOID PNK WIRE POWER WINDOW MASTER SWITCH RED WIRE REG SUNLIGHT SENSOR/AUTOMATIC LIGHTING CONTROL UNIT-SENSOR TAILLIGHT RELAY UNDER-DASH FUSE/RELAY BOX W/ AUTO POSITION SWITCH W/O AUTO POSITION SWITCH WHT WIRE

Go to component -> Instrument illumination circuit (1 of 3) -> SUNLIGHT SENSOR/AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
