Honda Fit GR (2019-2022) road departure mitigation ind Wiring diagrams
This page contains all the electrical diagrams for the component. road departure mitigation ind, in which he is found in the car Honda Fit GR (2019-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram road departure mitigation ind (1 of 2)
32 BIT MICROPROCESSOR
ABS IND.
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BRAKE SYSTEM IND
BRN WIRE
CABLE REEL
CHARGING SYSTEM IND
CIRCUIT
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE IND HOT (RED) WIRE
CRUISE CONTROL SYSTEM
DOWN
ECON SWITCH (IF EQUIPPED)
EPS IND
FAIL SAFE CIRCUIT
FORCED TURNING OFF CIRCUIT
FORCED TURNING ON CIRCUIT
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HIGH BEAM IND
IMMOBILIZER IND
INDICATOR DRIVE CIRCUIT
INFO UP
KEYLESS ACCESS CONTROL UNIT
KEYLESS ACCESS SYSTEM IND
LEFT TURN SIGNAL IND
LOW OIL PRESSURE IND
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND LAMP (MIL)
PARKING BRAKE SWITCH
PNK WIRE
PPL
RED WIRE
REGULATOR
REGULATOR AMP (SEGMENT)
RIGHT TURN SIGNAL IND
ROAD DEPARTURE MITIGATION IND
SEAT BELT REMINDER IND
SECURITY IND
SECURITY-IND BLINK CIRCUIT
SEL RESET
SELECT/RESET INFORMATION SWITCH
SPEAKER
SPEEDOMETER
SRS IND
SW REGULATOR (TFT)
TACHOMETER
TAN WIRE
TFT
TO ILLUMINATION ENCODER (DIAGRAM 3 OF 3)
TO STABILIZE CIRCUIT (DIAGRAM 3 OF 3)
TPMS IND
VSA IND
VSA OFF IND
W/ DASHLIGHTS BRIGHTNESS CONTROLLER
W/ KEYLESS ACCESS SYSTEM
WHT WIRE
Go to component -> Instrument cluster circuit, w/ multi-information display (1 of 3) -> ROAD DEPARTURE MITIGATION IND
Wiring diagram road departure mitigation ind (2 of 2)
32 BIT MICROPROCESSOR
ABS IND.
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BRAKE SYSTEM IND
BRN WIRE
CHARGING SYSTEM IND
CIRCUIT
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE IND HOT (RED) WIRE
CRUISE CONTROL SYSTEM
EPS IND
FAIL SAFE CIRCUIT
FORCED TURNING OFF CIRCUIT
FORCED TURNING ON CIRCUIT
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HIGH BEAM IND
IMMOBILIZER IND
INDICATOR DRIVE CIRCUIT
KEYLESS ACCESS SYSTEM IND
LEFT TURN SIGNAL IND
LOW OIL PRESSURE IND
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND LAMP (MIL)
PARKING BRAKE SWITCH
PNK WIRE
PPL
RED WIRE
REGULATOR
REGULATOR AMP (SEGMENT)
RIGHT TURN SIGNAL IND
ROAD DEPARTURE MITIGATION IND
SEAT BELT REMINDER IND
SECURITY IND
SECURITY-IND BLINK CIRCUIT
SPEAKER
SPEEDOMETER
SRS IND
SW REGULATOR (TFT)
TACHOMETER
TAN WIRE
TFT
TO ILLUMINATION ENCODER (DIAGRAM 3 OF 3)
TO STABILIZE CIRCUIT (DIAGRAM 3 OF 3)
TPMS IND
TPMS SWITCH (IF EQUIPPED)
VSA IND
VSA OFF IND
WHT WIRE
WIPER/WASHER SYSTEM
YEL WIRE
Go to component -> Instrument cluster circuit, w/o multi-information display (1 of 3) -> ROAD DEPARTURE MITIGATION IND
