Honda Fit GR (2019-2022) cmbs off/ rdm switch Wiring diagram
This page shows the only wiring diagram for the component.cmbs off/ rdm switch, which is found in the car Honda Fit GR (2019-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cmbs off/ rdm switch (1 of 1)
A/C SWITCH
AUTOMATIC A/C
BLK WIRE
CABLE REEL
CAN GATEWAY
CEILING LIGHT
CLIMATE CONTROL UNIT
CMBS OFF/ RDM SWITCH
COMBINATION LIGHT SWITCH
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
CVT
DATA LINK CONNECTOR (DLC)
DRIVER'S DOOR KEY CYLINDER SWITCH
DRIVER'S DOOR LATCH
DRIVER'S DOOR LOCK KNOB SWITCH
DRIVER'S DOOR OUTER HANDLE
DRIVER'S SEAT HEATER SWITCH
ECON SWITCH
ELECTRIC STEERING LOCK
FRONT ACCESSORY POWER SOCKET
FRONT PASSENGER'S DOOR LOCK ACTUATOR/ KNOB SWITCH
FRONT PASSENGER'S DOOR OUTER HANDLE
FRONT PASSENGER'S SEAT HEATER SWITCH
FUEL TANK UNIT
GAUGE CONTROL MODULE
HEATER FAN SWITCH
IGNITION KEY SWITCH
IMMOBILIZER KEYLESS CONTROL UNIT
KEYLESS ACCESS CONTROL UNIT
LEFT POWER MIRROR
MICU
MOONROOF CONTROL UNIT/ MOTOR
MOONROOF SWITCH
MULTIPURPOSE CAMERA UNIT
PADDLE SHIFTER (-) (DOWN- -SHIFT SWITCH)
PADDLE SHIFTER+ (UP SHIFT SWITCH)
PARK PIN SWITCH/ SHIFT LOCK SOLENOID
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK/ UNLOCK)
POWER MIRROR SWITCH
POWER TRANSISTOR
POWER WINDOW MASTER SWITCH
REAR WINDOW DEFOGGER SWITCH
REAR WINDOW WASHER MOTOR RELAY
REAR WINDOW WIPER MOTOR RELAY
RIGHT POWER MIRROR
STEERING ANGLE SENSOR
SUNLIGHT SENSOR/ AUTOMATIC LIGHTING CONTROL UNIT-SENSOR
TAILGATE RELEASE ACTUATOR RELAY
TPMS SWITCH
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH RELAY HOLDER A BLOWER MOTOR RELAY
UNDER-DASH RELAY HOLDER B
VSA OFF SWITCH
W/ KEYLESS ACCESS SYSTEM
W/ MOONROOF
W/O KEYLESS ACCESS SYSTEM
W/O MOONROOF
WINDSHIELD WASHER MOTOR RELAY
Go to component -> Ground distribution circuit (2 of 3) -> CMBS OFF/ RDM SWITCH
