Honda Fit GP facelift (2017-2020) sel reset Wiring diagram
This page shows the only wiring diagram for the component.sel reset, which is found in the car Honda Fit GP facelift (2017-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sel reset (1 of 1)
32 BIT MICROPROCESSOR
ABS IND.
ANTI-LOCK BRAKES SYSTEM
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE IND
BRAKE SYSTEM IND
BRN WIRE
CABLE REEL
CHARGING SYSTEM IND
CIRCUIT
COMPUTER DATA LINES SYSTEM
COOLANT TEMPERATURE IND HOT (RED) WIRE
CRUISE CONTROL SYSTEM
DOWN
ECON SWITCH (IF EQUIPPED)
EPS IND
FAIL SAFE CIRCUIT
FORCED TURNING OFF CIRCUIT
FORCED TURNING ON CIRCUIT
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HIGH BEAM IND
IMMOBILIZER IND
INDICATOR DRIVE CIRCUIT
INFO UP
KEYLESS ACCESS CONTROL UNIT
KEYLESS ACCESS SYSTEM IND
LEFT TURN SIGNAL IND
LOW OIL PRESSURE IND
LT BLU WIRE
LT GRN WIRE
MALFUNCTION IND LAMP (MIL)
PARKING BRAKE SWITCH
PNK WIRE
PPL
RED WIRE
REGULATOR
REGULATOR (TFT)
REGULATOR AMP (SEGMENT)
RIGHT TURN SIGNAL IND
ROAD DEPARTURE MITIGATION IND
SEAT BELT REMINDER IND
SECURITY IND
SECURITY-IND BLINK CIRCUIT
SEL RESET
SELECT/RESET INFORMATION SWITCH
SPEAKER
SPEEDOMETER
SRS IND
TACHOMETER
TAN WIRE
TFT
TO ILLUMINATION ENCODER (DIAGRAM 3 OF 3)
TO STABILIZE CIRCUIT (DIAGRAM 3 OF 3)
TPMS IND
VSA IND
VSA OFF IND
W/ DASHLIGHTS BRIGHTNESS CONTROLLER
W/ KEYLESS ACCESS SYSTEM
WHT WIRE
Go to component -> Instrument cluster circuit, w/ multi-information display (1 of 3) -> SEL RESET
