Honda Fit GP facelift (2017-2020) reverse lockout solenoid Wiring diagrams
This page contains all the electrical diagrams for the component. reverse lockout solenoid, in which he is found in the car Honda Fit GP facelift (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
reverse lockout solenoid wiring diagram (1 of 3)
ABS/VSA MODULATOR CONTROL UNIT
AUDIO UNIT/ AUDIO NAVIGATION UNIT
AUXILIARY UNDER-HOOD RELAY BOX B
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CONNECTOR
CONSOLE ACCESSORY POWER SOCKET
CONSOLE ACCESSORY POWER SOCKET RELAY
CVT
ELECTRIC STEERING LOCK
EPS CONTROL UNIT
EVAP CANISTER PURGE VALVE
FROM ACCESSORY RELAY (DIAGRAM 6 OF 6)
FROM AUXILIARY UNDER-DASH FUSE BOX (DIAGRAM 1 OF 6)
FROM IGNITION SWITCH (DIAGRAM 4 OF 6)
FROM UNDER-DASH FUSE/RELAY BOX 2 OF 6)
FROM UNDER-DASH SUB RELAY BOX (DIAGRAM 6 OF 6)
FRONT ACCESSORY POWER SOCKET
FUSE 1
FUSE 26
FUSE 27
FUSE 28
FUSE 3
FUSE 30
FUSE 32
FUSE 36
FUSE 37
FUSE 38
FUSE 8
GRN WIRE
GRY WIRE
IGNITION KEY SWITCH
IMMOBILIZER KEYLESS CONTROL UNIT
KEYLESS ACCESS CONTROL UNIT
M/T
MAF SENSOR/ IAT SENSOR
MICU
OPTION
ORG/ WIRE
PCM
PGM-FI MAIN RELAY 2
POWER DOOR LOCK RELAY (DR UNLOCK)
POWER DOOR LOCK RELAY (LOCK/UNLOCK)
POWER WINDOW MASTER SWITCH
POWER WINDOW RELAY
PPL
RED WIRE
REVERSE LOCKOUT SOLENOID
SRS UNIT
STARTER CUT RELAY 1
STARTER CUT RELAY 2
STEERING ANGLE SENSOR
TAILGATE RELEASE ACTUATOR RELAY
TAN WIRE
TO ENGINE START/ STOP SWITCH (DIAGRAM 6 OF 6)
TO FUSE 34 (DIAGRAM 5 OF 6)
UNDER-DASH FUSE/RELAY BOX
UNDER-DASH RELAY HOLDER A
UNDER-HOOD FUSE/RELAY BOX
W/ KEYLESS ACCESS SYSTEM
W/O IMMOBILIZER W/ IMMOBILIZER
W/O KEYLESS ACCESS SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> REVERSE LOCKOUT SOLENOID
reverse lockout solenoid wiring diagram (2 of 3)
Go to component -> Reverse lockout circuit -> REVERSE LOCKOUT SOLENOID
reverse lockout solenoid wiring diagram (3 of 3)
Go to component -> Wiring diagram engine performance 1.5l (6 of 8) -> REVERSE LOCKOUT SOLENOID
