Honda Fit GP facelift (2017-2020) gauge control module Wiring diagrams

This page contains all the electrical diagrams for the component. gauge control module, in which he is found in the car Honda Fit GP facelift (2017-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

gauge control module wiring diagram (31 of 34)

12 VOLT BATTERY TERMINAL FUSE BOX 32 BIT MICROPROCESSOR ALTERNATOR BATTERY BATTERY SENSOR BLK WIRE CHARGING SYSTEM INDICATOR COMPUTER DATA LINES SYSTEM DRIVE CIRCUIT F-CAN F-CAN H F-CAN L FUSE 1 FUSE 15 FUSE 18 FUSE 2 FUSE 29 FUSE 34 GAUGE CONTROL MODULE HOT AT ALL TIMES HOT IN ON OR START INDICATOR LT BLU WIRE LT GRN WIRE MICU PCM PPL RED WIRE TRANSCEIVER/ UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT WIRE

Go to component -> Charging circuit -> GAUGE CONTROL MODULE

gauge control module wiring diagram (32 of 34)

12 VOLT BATTERY TERMINAL FUSE BOX 32 BIT MICROPROCESSOR BATTERY BATTERY SENSOR BLK WIRE BLK/WHT WIRE BLU WIRE CLUTCH PEDAL POSITION SWITCH A/C COMPUTER DATA LINES SYSTEM CVT DIODE A ENGINE START/STOP SWITCH F-CAN F-CAN H F-CAN L FUSE 13 FUSE 2 FUSE 25 FUSE 26 FUSE 29 FUSE 3 FUSE 34 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START KEYLESS ACCESS CONTROL UNIT LT BLU WIRE LT GRN WIRE M/T MAGNETIC SWITCH MICU PCM PNK PNK WIRE PNK WIRE PPL RED WIRE STARTER STARTER CUT RELAY 1 STARTER CUT RELAY 2 TOP OF TRANSMISSION) TRANSCEIVER/ TRANSMISSION RANGE SWITCH UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Starting circuit, w/ keyless access system -> GAUGE CONTROL MODULE

gauge control module wiring diagram (33 of 34)

12 VOLT BATTERY TERMINAL FUSE BOX 32 BIT MICROPROCESSOR AUXILIARY UNDER-DASH FUSE BOX BATTERY BATTERY SENSOR BLK WIRE BLK/WHT WIRE CLUTCH PEDAL POSITION SWITCH A/C CLUTCH PEDAL POSITION SWITCH B/D COMPUTER DATA LINES SYSTEM CVT DIODE A F-CAN F-CAN H F-CAN L FUSE 1 FUSE 1-2 FUSE 26 FUSE 29 FUSE 34 GAUGE CONTROL MODULE GRN WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION SWITCH LOCK LT GRN WIRE M/T MAGNETIC SWITCH MICU ORG/ WIRE PCM PNK WIRE RED WIRE STARTER STARTER CUT RELAY TOP OF TRANSMISSION) TRANSCEIVER/ TRANSMISSION RANGE SWITCH UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Starting circuit, w/o keyless access system -> GAUGE CONTROL MODULE

gauge control module wiring diagram (34 of 34)

32 BIT MICROPROCESSOR ANTI-THEFT SYSTEM BLK WIRE BLU WIRE BRN WIRE CLUTCH PEDAL POSITION SWITCH A/C COMPUTER DATA LINES SYSTEM CVT CVT M/T ECT SENSOR 2 EVAP CANISTER VENT SHUT VALVE EVAPORATOR TEMPERATURE SENSOR F-CAN H F-CAN L F-CAN TRANSCEIVER FUSE 30 FUSE 32 FUSE 34 FUSE 35 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT IN ON OR START INDICATOR DRIVE CIRCUIT INSTRUMENT CLUSTER SYSTEM LT BLU WIRE LT GRN WIRE MALFUNCTION INDICATOR LAMP (MIL) MICU ORG/ WIRE PGM-FI MAIN RELAY 2 PNK WIRE PPL RED WIRE STARTING/CHARGING SYSTEM UNDER-DASH FUSE/RELAY BOX WHT WIRE YEL WIRE

Go to component -> Wiring diagram engine performance 1.5l (2 of 8) -> GAUGE CONTROL MODULE
