Exterior lamps circuit for Honda Fit GE (2007-2014)

B-CAN BLK WIRE BLU WIRE BRAKE PEDAL POSITION SWITCH (TOP OF BRAKE PEDAL SUPPORT) BRN WIRE CLUSTER COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM ENGINE CONTROL SYSTEM FUSE 23 FUSE 24 FUSE 29 GRY WIRE H/L ON SW SMALL LT SW H/L OFF SW COMBI GND TURN R SW TURN L SW HAZ SW HEAD HEADLIGHT SWITCH HOT AT ALL TIMES HOT AT ALL TIMES UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) LEFT LEFT FRONT PARKING/ SIDE MARKER LIGHT LEFT LEFT REAR TURN SIGNAL LIGHT FRONT TURN SIGNAL LIGHT LT GRN WIRE MICU OFF HEAD P-GND PARK PARK OFF PNK WIRE RED WIRE RIGHT RIGHT FRONT PARKING/ SIDE MARKER LIGHT RIGHT FRONT TURN SIGNAL LIGHT RIGHT REAR TURN SIGNAL LIGHT S GND STOP SW TAILLIGHT RELAY TURN SIGNAL SWITCH TURN SIGNAL/ HAZARD WARNING CIRCUIT WHT WIRE YEL WIRE

+B BACK UP A/T AREA NETWORK TRANSCEIVER BLK WIRE BLU WIRE BODY CONTROLLER CIRCUIT COMPUTER DATA LINES SYSTEM DRIVE CIRCUIT FUSE 1 FUSE 22 GAUGE CONTROL MODULE GRY WIRE HAZARD WARNING SWITCH HIGH MOUNT BRAKE LIGHT HOT AT ALL TIMES HOT IN ON OR START INDICATOR DIMMING CIRCUIT INTERIOR LIGHT SYSTEM LEFT BRAKE LIGHT/ TAILLIGHT LEFT LICENSE PLATE LIGHT LEFT TURN SIGNAL IND LIGHTS ON INDICATOR LT BLU WIRE LT GRN WIRE METER MICU NETWORK CONTROLLER PNK WIRE RED WIRE RELAY 2 (SOUNDER) RIGHT BRAKE LIGHT/ TAILLIGHT RIGHT LICENSE PLATE LIGHT RIGHT TURN SIGNAL IND SHIFT INTERLOCK SYSTEM TURN SIGNAL/HAZARD UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) WARNING WHT WIRE WHT/BLK WIRE YEL WIRE
