Honda Fit GE (2007-2014) maf iat sensor sensor Wiring diagram

This page shows the only wiring diagram for the component.maf iat sensor sensor, which is found in the car Honda Fit GE (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram maf iat sensor sensor (1 of 1)

Wiring diagram maf iat sensor sensor for Honda Fit GE (2007-2014)

Get access

+B BACK UP A/T A/T M/T BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE ETCS CONTROL RELAY FUEL PUMP FUEL TANK UNIT (IN FUEL TANK) FUSE 1 FUSE 20 FUSE 22 FUSE 33 FUSE 39 FUSE 52 GRN WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION COIL RELAY LT BLU WIRE LT GRN WIRE M/T MAF IAT SENSOR SENSOR MAF/IAT SENSOR (ON AIR INTAKE DUCT) METER MICU MICU FUEL PUMP ORG/ WIRE PGM-FI MAIN RELAY 1 PGM-FI MAIN RELAY 2 PNK WIRE PPL PPL PNK WIRE RED WIRE RED/WHT WIRE SHIFT INTERLOCK SYSTEM TAN WIRE UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) WHT WIRE YEL WIRE

Go to component: -> Wiring diagram engine performance 1.5l (4 of 5) -> MAF IAT SENSOR SENSOR
