Honda Fit GE (2007-2014) left power mirror Wiring diagram
This page shows the only wiring diagram for the component.left power mirror, which is found in the car Honda Fit GE (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left power mirror (1 of 1)
A/C SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
COIL
DEFOGGER
FUSE 10
FUSE 54
FUSE 55
FUSE 59
GRY WIRE
H/MIRR
HAC
HOT AT ALL TIMES
HOT IN ON
J/C
LEFT POWER MIRROR
MICU +B
NCA WIRE
ORG/ WIRE
PPL
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER RELAY
REAR WINDOW/ POWER MIRROR DEFOGGER SWITCH
RED WIRE
RIGHT POWER DEFOGGER MIRROR
RR DEF
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
Go to component: -> Defoggers circuit, with power mirror defogger -> LEFT POWER MIRROR
