Honda Fit GE (2007-2014) left left rear turn signal light front turn signal light Wiring diagram
This page shows the only wiring diagram for the component.left left rear turn signal light front turn signal light, which is found in the car Honda Fit GE (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left left rear turn signal light front turn signal light (1 of 1)
B-CAN
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH (TOP OF BRAKE PEDAL SUPPORT)
BRN WIRE
CLUSTER
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL SYSTEM
FUSE 23
FUSE 24
FUSE 29
GRY WIRE
H/L ON SW SMALL LT SW H/L OFF SW COMBI GND TURN R SW TURN L SW
HAZ SW
HEAD
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH)
LEFT
LEFT FRONT PARKING/ SIDE MARKER LIGHT
LEFT LEFT REAR TURN SIGNAL LIGHT FRONT TURN SIGNAL LIGHT
LT GRN WIRE
MICU
OFF HEAD
P-GND
PARK
PARK OFF
PNK WIRE
RED WIRE
RIGHT
RIGHT FRONT PARKING/ SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT REAR TURN SIGNAL LIGHT
S GND
STOP SW
TAILLIGHT RELAY
TURN SIGNAL SWITCH
TURN SIGNAL/ HAZARD WARNING CIRCUIT
WHT WIRE
YEL WIRE
Go to component: -> Exterior lamps circuit (1 of 2) -> LEFT LEFT REAR TURN SIGNAL LIGHT FRONT TURN SIGNAL LIGHT
