Honda Fit GE (2007-2014) high mount Wiring diagram
This page shows the only wiring diagram for the component.high mount, which is found in the car Honda Fit GE (2007-2014). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high mount (1 of 1)
AUDIO UNIT (W/O NAVIGATION)
AUDIO-NAVIGATION UNIT (W/ NAVIGATION)
BLK WIRE
BRAKE LIGHT
DEFOGGER
DRIVER'S SEAT BELT BUCKLE SWITCH
DRIVER'S SEAT POSITION SENSOR
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
HIGH MOUNT
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT LICENSE PLATE LIGHT
LEFT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH (W/ POWER DOOR LOCKS)
LEFT REAR TURN LEFT SIGNAL BACKUP LIGHT LIGHT
ODS UNIT
REAR WINDOW
REMOTE STARTING CONTROL UNIT GROUND
REMOTE STARTING SYSTEM CONNECTOR 1 (OPTION CONNECTOR)
RIGHT LICENSE PLATE LIGHT
RIGHT REAR DOOR LOCK ACTUATOR/ KNOB SWITCH (W/ POWER DOOR LOCKS)
RIGHT REAR TURN SIGNAL LIGHT
RIGHT RIGHT BRAKE BACKUP LIGHT/ LIGHT TAILLIGHT
SECURITY GROUND
SRS UNIT
TAILGATE LATCH SWITCH
W/ HONDA ACCESSORY
WHT WIRE
WIPER MOTOR
YEL WIRE
Go to component: -> Ground distribution circuit (3 of 3) -> HIGH MOUNT
