Honda Fit GE (2007-2014) can-l computer data lines system Wiring diagram

A/T ANGLE SENSOR BATTERY TERMINAL FUSE BOX (ON BATTERY) BLK WIRE BLU WIRE BRN WIRE CAN L CAN-H CAN-H PPL COMPUTER DATA LINES SYSTEM K-LINE CAN-L COMPUTER DATA LINES SYSTEM COMPULSORY TURNING- ON CIRCUIT COMPUTER DATA LINES SYSTEM CONNECTOR ECM/PCM (LEFT SIDE OF ENGINE COMPT) EPS CONTROL UNIT (LEFT END OF DASH) EPS INDICATOR EPS MOTOR EPS MOTOR ANGLE SENSOR EPS MOTOR CONNECTOR EPS TORQUE SENSOR FAIL SAFE CIRCUIT FAST CONTROLLER AREA NETWORK TRANSCEIVER FUSE 11 FUSE 2 FUSE 22 GAUGE CONTROL MODULE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START LT BLU WIRE LT GRN WIRE MAIN MICU METER MV MU MW NEP NEP PG (LEFT SIDE OF DASH) +B NETWORK CONTROLLER ORG/ WIRE PNK WIRE PPL RED WIRE SG PNK WIRE STEERING GEARBOX SUB + UNDER-DASH FUSE/RELAY BOX (UNDER LEFT END OF DASH) VCC VCC MAIN SE SUB VREF WARNING DRIVE CIRCUIT WHT WIRE YEL WIRE
