Honda Elysion II (2021-2024) wht/red Wiring diagram
This page shows the only wiring diagram for the component.wht/red, which is found in the car Honda Elysion II (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram wht/red (1 of 1)
2.5L 3.6L
2.5L A/T
2.5L M/T
2.8L TURBO DIESEL
3.6L 2.8L TURBO DIESEL
6 SPEED A/T
8 SPEED A/T
ACC VOLT
AUTOMATIC TRANSMISSION ASSEMBLY
BATT POSITIVE VOLT
BCM 2 FUSE
BLK WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BLK/YEL WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR
BRK APPLY SENS SIG
BRK APPLY SENS SPLY VOLT
BRK POS SENS LOW REF
BRK POS SENS SIG 41 25 BRK POS SENS 5 VOLT REF
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
DLIS FUSE
ENGINE CONTROL MODULE (UNDER COOLANT RESERVOIR)
GRY WIRE
HI SPD GMLAN SERIAL DATA (-) (1)
HOT AT ALL TIMES
IGNITION SWITCH
IMS MODE SW RTN
INSTRUMENT PANEL FUSE BLOCK
KEY CAPTURE SOLENOID ACTUATOR
KEY-IN IGNITION SWITCH
LOCK SHIFT POS SIG
LOW REF
LT BLU WIRE
NCA WIRE
OFF
OFF/RUN/CRANK VOLT
PARK LOCK SOL CTRL
PARK POSITION SWITCH
PARK/NEUTRAL SIG (1)
RED WIRE
RED/BRN WIRE
RED/LT BLU WIRE
RUN WIRE
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
VIO/BLK WIRE
VIO/YEL WIRE
WHT WIRE
WHT/GRY WIRE
WHT/LT GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
Go to component: -> Shift interlock circuit -> WHT/RED WIRE
